Summary of Contents for PR Lighting XR-230 BEAM
- Page 1 XR-230 BEAM PR-2207 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
Any future technical change in the user manual won’t be with any notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty... -
Page 3: Safety And Warnings
1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Goggles Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. -
Page 4: Instructions
Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord ●... -
Page 5: Apperance
●LUBRICATION To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. ●TROUBLESHOOTING PROBLEM ACTION ... - Page 6 Remarks: 1. The Distance between the top of the feet and the top the head; 2. The distance between the top of the mounting bar and the top of the head; 3. The head’s rotating diameter( the minimum distance between 2 neighboring projectors on the truss) Warning!
- Page 7 Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
-
Page 8: Setup And Tonfiguration
Figure2: lamp adjustment 2. Use a cross-screw driver to 3. Use cross-screw driver to 示例2：调节灯泡 2、用十字螺丝刀调松灯泡一测的 3、用十字螺丝刀调节两颗螺丝即 loosen the tightening screw on 1.Use a cross-screwdriver to 1、用十字螺丝刀拆开两侧风扇组 压紧螺丝 可调节灯泡位置 adjust both screws to adjust the one side of the lamp; remove the screws of fans on its 件螺丝，打开风扇... - Page 9 To set or browse through its functions, press or DOWN key DOWN Press ENTER key to save the changes or enter into the sub menus. Press key to change the numbers(minus or plus). FUNC FUNC Press key to go to the upper menu. If key is not pushed, the system will go back to initial status automatically.
-
Page 10: Operation Menu
Slave Slave Master Terminator Input Output Input Output 6. OPERATION MENU level menu level menu level menu level menu level menu Address 1-500（Short Mode） DMX Address 1-499（Standard Mode） 1-497（Extended Mode） Really Reset? Total Reset Confirm or Cancel Really Reset? Pan&Tilt Reset Confirm or Cancel Really Reset? Colour System Reset... - Page 11 XLR Only Signal Select XLR First （Wireless control is only Wireless Only available for the fixtures with wireless control module） Wireless First Wireless In/XLR Out Normal time out Loss of DMX Hold Last Value Off After Delay Display Mode On Always Display Config English\Chinese Language Setting...
- Page 12 Channel Value Strobe × × × View DMX Values … … … … Lamp Hours =× × × × Lamp Hours Reset Lamp Hours Total Hours Total Hours=× × × × Display Board = × × × C Pan&Tilt Board = × × × C Temperature Driver Board = ×...
- Page 13 Change Operation Mode? User Memory 1 Confirm or Cancel Change Operation Mode? User Memory 2 Confirm or Cancel Change Operation Mode? Preset Memory Confirm or Cancel Change Operation Mode? User Memory 1 Stand-Alone Mode Confirm or Cancel Change Operation Mode? User Memory 2 Confirm or Cancel Change Operation Mode?
-
Page 14: Dmx Protocol
7. DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode Mode Close 000-010 Open 011-025 Strobe 026-225 Strobe speed from slow to fast 226-246 Macros (Strobe at random ) 247-255 Open Close 000-008 Dimmer （0-100%） 009-255 Linear dimming Dimmer Fine 000-255 Dimmer in 16 bit 000-011... - Page 15 000-021 White 022-027 Gobo1 028-033 Gobo2 034-039 Gobo3 040-045 Gobo4 046-051 Gobo5 052-057 Gobo6 058-063 Gobo7 064-069 Gobo8 070-075 Gobo9 076-081 Gobo10 082-087 Gobo11 088-093 Gobo12 094-099 Gobo13 100-105 Gobo14 106-111 Gobo15 112-119 Gobo16 118-123 Gobo17 Fixed Gobo Wheel 124-127 Open 128-157 Clockwise rotation from slow to fast...
- Page 16 189-195 Stop 196-255 Rotation(Clockwise from slow to fast) 000-255 Focus Linear Focus 000-255 Focus Fine Focus in 16 bit precision 000-255 Pan(0° ~540° ) Pan Fine 000-255 Pan in 16 bit Tilt 000-255 Tilt(0° ~270° ) Tilt Fine 000-255 Tilt in 16 bit 000-255 Pan &...
-
Page 17: Signs On Touch Screen
8. SIGNS ON TOUCH SCREEN Option Settings Lamp Control Information Chinese/English Service Error Messages Operation Mode Address Reset User Memories Config Settings 9.ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows Name Type... -
Page 18: Technical Data
10.TECHNICAL DATA ELECTRIC PARAMETERS ，50/60Hz Input voltage 200V~240V AC Input power 310W@220V Power factor PF>0.90 MAX. Current: 1.5A @ 220V THE SPECIFICATIONS OF THE LAMP DARK SIRIUS HRI 231W Osram PURPLE 7900K Color temperature LIGHT GREEN CYAN Rated life 2000hrs BLUE Energy save mode 2500hrs... - Page 19 HEAD MOVEMENT Pan 540º , Tilt 270º with 16 bit control BEAM ANGLE 0° ～ 3.6° CONTROL International standard DMX 512 protocol, 5-pin interface 13channels in short mode ,14channels in standard mode and16 channels in extended mode Adjusting mode OPERATION TEMPERATURE Maximum ambient temperature 40°...
-
Page 20: Circuitdiagram
LIGHT OUTPUT 1508519 377130 167613 94282 60341 41903 DISTANCE（m） DIAMETER（m） 0.65 0.97 1.29 1.61 1.94 0.32 11.CIRCUITDIAGRAM... -
Page 22: Component Order Codes
12.COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 230W BALLAST 040070112 231W LAMP 100070048 SWITCHING POWER SUPPLY 192010238 030060069 FG+PWM SPEED ADJUSTING FAN 030060122 FG+PWM SPEED ADJUSTING FAN 030060115 FG+PWM SPEED ADJUSTING FAN 030060126 BLOWER 030060072A PAN MOTOR 030040160A TILT MOTOR PRISM WHEEL IN/OUT MOTOR 030040307 GOBO WHEEL MOTOR... -
Page 23: Appendix
APPENDIX: Some Advice on the Use of a Projector For the effective extension of the lifespan of discharge lamp, some factors impacting its lifespan are specially listed below, based on manufacturing technology and working mechanism of discharge lamps, i.e., physical attributions of the lamps including lamp striking theory( ignited by focused high voltage---highly pressurized air broken down and burning---lamp on at high temperature with thermal protection--- stable running) and lamp off theory( lamp off power ---lamp off at high temperature and thermal protection-highly pressurized air vaporizing evenly----completion of lamp off. - Page 24 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! 320021462...
