Connecting the supply
voltage or signal cable

Service connector

Technical data

Control drawings

8
The terminal assignment and the connection data for the supply voltage are identical for all devices, regardless
of the device version (type code).
!
Note!
A graphic illustration of the electrical connections is provided on Page 7.
Terminal assignment /connection data
Prosonic 92F**-***********A
Prosonic 92F**-***********W
Prosonic 92F**-***********H
Prosonic 92F**-***********K
The service connector (for connection, see Fig. 3 to Fig. 7, e) is only used to connect service interfaces
approved by Endress+Hauser.
#
Warning!
The service connector may not be connected in a potentially explosive atmosphere.
Dimensions
The dimensions of the Ex transmitter housing and the sensor correspond to the standard versions.
Please refer to the Technical Information for these dimensions.
!
Note!
Associated "Technical Information":
Proline Prosonic Flow 92F TI073D/06/...
Endress+Hauser Reinach hereby declares that the product is in conformitywith the requirements of the
FACTORY MUTUAL standards.
!
Note!
The "Documentation/Important Information" folder provided with the measuring device contains a CD-ROM
with all the Control Drawings.
Terminals 1 (+)
Terminal Transmitter power supply /
designation 4 to 20 mA HART
Safety-related
 35 V (U
max
values
Terminals 1 (+)
Terminal
designation
Safety-related
values
Terminals 1 (+)
Terminal
designation
Safety-related
values
Proline Prosonic Flow 92F
2 (–) 3 (+)
Optional
pulse/status output
 35 V (U
= 250 V) = 250 V)
max
2 (–)
PROFIBUS PA
U = 35 V
(U = 250 V)
max
2 (–)
FOUNDATION Fieldbus
U = 35 V
(U = 250 V)
max
Endress+Hauser
4 (–)
