Gossen MetraWatt SECUTEST BASE Quick Start Manual page 11

Test Instruments for Measuring Electrical Safety of Devices
Order Information for Accessories
Designation
Mains power cable
Cable set for connecting test instruments
to the mains without using a an earthing
contact outlet, and for connecting DUTs.
Consists of coupling socket with 3 perma-
nently connected cables, 3 measurement
cables, 3 plug-on pick-up clips and 2 plug-
on test probes.
Adapter for testing 3-phase current consumers
Adapter for connecting DUTs:
3-pole 16 A, 5-pole 16 A + 32 A,
5 ea. 4 mm socket
– For all tests without line voltage
at single and 3-phase electrical devices
– for differential current measurements
(direct or differential current method)
16 A / 32 A 3-phase current adapter (test case)
– For all tests without line voltage at single
and 3-phase electrical devices
– For tests at single
and 3-phase extension cords
– For differential current measurements
(direct method)
– für leakage current measurements in
accordance with differential current
1
method
Test adapter for tests on devices with
CEE16 and CEE32 connections
(load rating of max 20 A)
same as AT3-II-S, however, with a load
rating of 32 A
3-phase 16 A differential current adapter
3-phase 32 A differential current adapter
Test adapter with single and 3-phase plug
connectors up to CEE 32A
– For all tests without line voltage at single
and 3-phase electrical devices
– For tests at single
and 3-phase extension cords
Adapter cable CEE 16 A 5-pin plug red on
CEE 32 A 5-pin coupling red, 0.5 m,
5 x 1.5 mm²
Adapter for testing single-phase extension cables
Adapter for testing single-phase extension
cables including earth contact and inlet
plug inserts
Plug insert for using adapter EL1
in Switzerland
Adapter for testing welding units
Test adapter in combination with
SECUTEST... for testing welding units per
DIN EN 60974-4:2007.
The peak-value rectifier in the SECULOAD-
N uses the 1N4007 rectifier diode recom-
mended in the standard.
This is a mains rectifier diode which, due to
its design, is only suitable for voltage
sources with low cycle rates within the
range of the line frequency, or voltage
sources with conventional transformer.
Includes 4 measurement cables and 2 alli-
gator clips.
GMC-I Messtechnik GmbH
SECUTEST
Type Article number
KS13 GTY3624065P01
CEE Adapter Z745A
D
AT3-III-E Z745S
D 1
AT3-IIS Z745T
D 1
AT3-II S32 Z745X
AT16-DI Z750A
AT32-DI Z750B
VL2E Z745W
Adapter cable
CEE16/CEE32 Z750F
EL1 Z723A
PRO-CH GTZ3225000R0001
SECULOAD-N Z745R
B / P and SECULIFE ST
ASE RO
Designation
Calibration adapter
Calibration adapter for test instruments per
DIN VDE 0701-0702/IEC 62353
(VDE 0751) (max. 200 mA) cannot be
used for 10 A protective conductor test
current
Probe cable
Probe with probe tip and 2 m probe cable
(not coiled), 25 A short-circuit operation:
„on-time" 60 s, „resting time" 120 s
for SECULIFE ST BASE25
Probe cable with test probe and 2 m probe
cable (not coiled), 300 V CAT II 16 A
Probe cable with test probe and 2 m probe
cable (coiled), 300 V CAT II 16 A
5 m probe cable for protective conductor
measurement, 300 V CAT II 16 A
Brush probe
Multiple probe connector for connecting 5
• 4 mm and 5 • 2 mm test probes to mea-
sure multiple touchable housing parts or
application parts.
Cable set (1 pair of measuring cables) 1.2 m,
with VDE-GS sign 1000 V/CAT III 1 A,
600 V/CAT IV 1 A,
1000 V/CAT II 16 A* KS17-2
2 each in plastic bag, diameter 4 mm, length
1.0 m, 1000 V CAT III, 19 A, blue
2 each in plastic bag, diameter 4 mm, length
1.0 m, 1000 V CAT III, 19 A, black/red
Clip-on current sensor for SECUTEST PRO/SECULIFE ST BASE(25)
Clip-on current sensor, can be set to
1 mA to 15 A or 1 A to 150 A,
frequency range: 45 ... 65 ...500 Hz,
1 mV/mA and 1 mV/A
Leakage current clamp 0.1 mA ... 25 mA,
100 mV/mA
Temperature sensors for SECUTEST PRO/SECULIFE ST BASE(25)
Pt100 temperature sensor for surface and
immersion measurement, –40 to + 500 °C
Pt1000 temperature sensor for measure-
ment in gases and liquids,
–50 ... +220 °C
Pt100 oven sensor,
Pt100, –50 ... +550 °C
Sounding pipe oil temperature sensor,
Pt1000 class B, –50...+500 °C, sensor 3
mm dia. x 810 mm length
BASE(25)
Type Article number
SECU-cal 10 Z715A
SK2-25A Z746C
SK2 Z745D
SK2W Z745N
SK5 Z745O
Z745G Z745G
SV5 Z745J
GTY3620034P0002
Cable set blue Z746A
Cable set bw/rd Z746B
D)
WZ12C Z219C
D)
SECUTEST CLIP Z745H
Z3409 GTZ3409000R0001
TF220 Z102A
TF550 GTZ3408000R0001
TF400CAR Z102C
11
