Test Instruments for Measuring Electrical Safety of Devices
Overview of Features Included with SECUTEST BASE, SECUTEST PRO and SECULIFE ST BASE(25) Test Instruments
Switch Measuring Function,
Set- Test Current/Voltage
ting
Single measurements, rotary switch level: green
R
R Protective conductor resistance
PE
PE
I Test current (200 mA)
SECUTEST BASE10/PRO:
and SECULIFE ST BASE 10 A
& SECULIFE ST BASE25: 25 A
R R Insulation resistance
ISO
ISO
U Test voltage
ISO
I I Protective conductor current, RMS value Direct
PE
PE
I AC component
PE~
I DC component
PE=
U Test voltage
LN
I I Touch current, RMS value
B
T
I AC component
T~
I DC component
T=
U Test voltage
LN
I I Device leakage current, RMS value
G
E
I AC component
E~
I DC component
E=
U Test voltage
LN
I I Leakage current from the application part,
A
A
RMS value
U Test voltage
A
I I Patient leakage current, RMS value
P
P
I AC component
P~
I DC component
P=
U Test voltage
LN
U U Probe voltage, RMS
U Alternating voltage component
~
U Direct voltage component
=
U Measurement Voltage RMS
U Alternating voltage component
~
U Direct voltage component
=
4
ta t PRCD time to trip for 30 mA PRCDs
B
U Line voltage at the test socket
LN
P Function test at the test socket
I Current between L and N
U Voltage between L and N
f Frequency
P Active power
S Apparent power
PF Power factor
Probe measuring functions
EL1 Extension cords with adapter:
continuity, short-circuit, polarity (wire reversal
EXTRA Reserved for expansion during the course of software updates
°C Temperature measurement
IZ Measurement of current at clamp with
current clamp sensorn
1
10 A/25 A
-R measurements are only possible with line voltages of 115/230 V
PE
and line frequencies of 50/60 Hz.
2
Voltage mesurement inputs only with SECUTEST PRO (or device with Feature I01) and
SECULIFE ST BASE(25)
3 nd
Terminal for 2 test probe for 2-pole measurement only with SECUTEST PRO (or de-
SECULIFE ST BASE(25)
vice with Feature H01) and
4
Measurement of time to trip not possible in IT systems
5
No checking for reversed polarity takes place when the EL1 adapter is used.
2
/ P and SECULIFE ST
RO
Measurement
Type
Connection Type
PE(TS) - P1 passive
PE(TS) - P1 active
PE(Mains) - P1
1
PE(Mains) - P1 Clamp
(Feature G01)
3
1) P1 - P2
(Feature G02)
LN(TS) - PE(TS)
LN(TS) - P1
3
P1 - P2
PE(Mains) - P1
PE(TS) - P1
LN(TS) - P1//PE(TS)
Differential
Alternative
2
AT3-Adapter
2
Clamp
Direct
Differential
Alternative (P1)
Permanent connection
Alternative (P1–P2)
Direct
Differential
Alternative
2
AT3-Adapter
2
Clamp
Direct (P1)
Alternative (P1)
Permanent conn. (P1)
Direct (P1)
Permanent conn. (P1)
PE - P1
PE - P1 (with mains*)
* polarity preset
2
V – COM
2
V – COM (with mains)
2
Polarity preset
EL1 adapter
5
) AT3-IIIE adapter
VL2E adapter
2
with Pt100/Pt1000 V – COM
V – COM
BASE(25)
Key
Alternative = alternative measurement
(equivalent leakage current measurement)
Differential = differential current measurement
Direct = direct measurement
LN(TS) = short-circuited conductors L and N of test socket
P1 = measurement with test probe P1
2
P1-P2 = 2-pole measurement with test probe P1 & P2
PE-P1 = measurement between PE and test probe P1
PE(TS) = protective conductor of test socket
PE(Mains) = protective conductor of mains terminal
Switch Standard
Setting
Automated test sequences, rotary switch level: orange
Preconfigured (freely configurable) test sequences – Delivery Status
A1 VDE 0701-0702
A2 VDE 0701-0702
A3 VDE 0701-0702-IT
A4 IEC 62353 (VDE 0751) Passive measurement type
A5 IEC 62353 (VDE 0751) Active measurement type
A6
IEC 60974-4
A7 IEC 60974-4
A8 VDE 0701-0702
AUTO VDE 0701-0702
Display with Selectable Language
The display panel consists of a backlit, color multi-display at
which menus, setting options, measurement results, instructions
and error messages, as well schematic and wiring diagrams
appear.
The display and user prompting can be set to the desired lan-
guage depending on the country in which the test instrument is
used.
Data Entry
Data can be entered, for example, via a barcode reader con-
nected to the USB port, a RFID scanner, a USB keyboard, or via
the softkey keyboard when it appears at the display.
The touch screen of SECUTEST PRO (or devices with Feature E01)
and SECULIFE ST BASE(25) allows for the convenient entry of data
and comments while menu control is still based on softkeys.
Creating a Database
A complete test structure with data regarding customers, build-
ings*, floors*, rooms* and test objects can be created in the test
instrument. This structure makes it possible to assign single mea-
surements or test sequences to devices under test belonging to
various customers. Manual single measurements can be grouped
together into a so-called "manual sequence".
The SECUTEST PRO and SECULIFE ST BASE(25) test instruments and
those instruments with database expansion (Feature KB01)
enable the user to prepare a test structure by means of the
IZYTRONIQ software at the PC for subsequent transmission to the
test instrument.
* only with SECUTEST PRO or with database expansion (Feature KB01) and SECULIFE
ST BASE(25)
Measurement Type, Connection Type
Passive measuring method, test socket
Active measurement type, test socket
Parameters configuration for EDP (active)
Connection type: test socket
Connection type: AT16-DI/AT32-DI
VDE 0701-0702, measurement type Extension Cord
test (RPE, RISO), EL1/VL2E/AT3-IIIE adapter
Active measurement type, test socket
