Test Instruments for Measuring Electrical Safety of Devices
Reference Ranges
230 V AC ±0.2%
Line voltage
50 Hz ±2 Hz
Line frequency
Waveform
Sine (deviation between effective and rectified value < 0.5%)
Ambient temperature +23 °C ±2 K
40 ... 60%
Relative humidity
Load resistance Linear
Nominal Ranges of Use
100 V ... 240 V AC
Nominal line voltage
Nominal line frequency50 Hz ... 400 Hz
Line voltage waveform Sinusoidal
0 °C ... + 40 °C
Temperature
Ambient Conditions
Storage temperature – 20 °C ... + 60 °C
Relative humidity Max. 75%, no condensation allowed
Elevation Max. 2000 m
Deployment Indoors, except within specified ambient
conditions
Power Supply
Electrical system TN, TT or IT
100 V ... 240 V AC
Line voltage
Line frequency 50 Hz ... 400 Hz
Power consumption 200 mA test:
10 A test:
Mains to test socket
(e. g. function test) Continuous max. 3600 VA, power is con-
ducted through the instrument only,
switching capacity ≤ 16 A, ohmic load;
for currents > 16 A AC please use the
adapter AT3-IIS32 (Z745X)
Electrical Safety
Protection class I per IEC 61010-1/EN 61010-1/ VDE 0411-1
Nominal voltage 230 V
Test voltage 2.3 kV AC 50 Hz or 3.3 kV DC
(mains circuit / test socket to mains PE termi-
nal, USB, finger contact, probe, test socket)
Measuring category 250 V CAT II
Pollution degree 2
Safety shutdown At DUT differential current of > 10 mA,
shutdown time: < 100 ms,
can also be set to > 30 mA
with following probe current during:
– Leakage current meas.:
> 10 mA~/< 5 ms
– Protective conductor resistance meas.:
> 250 mA~/< 1 ms
At continuous flow of current I > 16,5 A
Fuse links Mains fuses:
Probe fuse:
SECUTEST BASE10/PRO/
SECULIFE ST BASE:
Additionally (Feature G01) 1 ea. FF 500V/16A
GMC-I Messtechnik GmbH
SECUTEST B
ASE
approx. 32 VA
approx. 105 VA
2 ea. FF 500V/16A
M 250V/250mA
/ P and SECULIFE ST
RO
Electromagnetic Compatibility
Product standard DIN EN 61326-1
Interference Emission
EN 55011
Interference immunity
EN 61000-4-2 Contact/atmos. – 4 kV/8 kV
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-11
USB Data Interface
Type USB slave for PC connection
Type 2 ea. USB master for data input devices*
with HID-Boot interface,
for USB stick for data backup,
for USB stick for storing reports as bmp
files, for printer*
* compatible devices see next page
As of firmware version 1.6.0: In the remote operating mode, the test
instrument can be controlled via the USB slave data interface.
Pertinent interface commands are available upon request.
®
Bluetooth 2.1 + EDR Data Interface
(SECUTEST PRO BT comfort only or feature M01)
Type for remote control
Mechanical Design
Display 4.3" color display (9.7 x 5.5 cm),
backlit, 480 x 272 pixels at 24 bit color
depth, (true color)
Touch screen with SECUTEST PRO/SECULIFE ST BASE(25)
or feature E01
(touch-sensitive user interface)
Dimensions W x H x D: 295 x 145 x 150 mm
Height with handle: 170 mm
Weight SECUTEST BASE(10)/PRO: Approx. 2.5 kg
SECULIFE ST BASE25: approx. 4.0 kg
Protection Housing: IP 40
Test socket: IP 20 per DIN VDE 0470,
part 1/EN 60529,
SECULIFE ST BASE(25): Housing with antimicro-
bial properties in accordance with the JIS-
Standard Z 2801:2000
BASE(25)
Class
Test value Evaluation criterion
3 V/m or 1 V/m
1 kV
1 kV or 2 kV
3 V/m
0.5/1/25 periods
250 periods
B
A
A
B
A
A
A
C
