Cockpit - Maxxus CX 3.0 Installation & Operating Manual

Cockpit

USB port with charging function
LCD display
Storage compartment for
Smartphone, Tablet PC
Recovery pulse measurement
Body fat analysis
The cockpit constantly displays the current training values.
TIME
For a specified training time the computer counts the time down backwards to "00:00". The training time can be
set from 01:00 to 99:00 minutes in one-minute increments.
If the training time is not set, the computer counts the training time from 00:00 to a maximum of 99:00 minutes.
DISTANCE
Displays the training distance in kilometres. For a specified training session, the computer counts the distance
down backwards to 0.00. The training distance can be specified from 1.0 to 99.0 kilometres in 1.0 km incre-
ments. If the training distance is not specified, the computer counts the training time from 0.0 to maximum 99.0
kilometres.
CALORIES*
Indication of calorie consumption in Kcal. With a specified calorie consumption, the computer counts the calories
down backwards to 0. The calorie consumption can be specified from 10 to 990 Kcal in 10-Kcalorie increments.
If the calorie consumption is not specified, the computer counts the calories from 0 to a maximum of 990 Kcal.
PULSE
When using the hand pulse sensors, displays the current pulse value in beats per minute. When using an op-
tionally available transmitter chest belt (not included) displays the current heart rate in beats per minute.
SPEED
Displays the current speed in km / h. Value is displayed alternately with RPM in the same window.
Revolutions per Minute – RPM
Displays the current wheel revolutions per minute (RPM). Value is displayed alternately with speed in the same
window.
RECOVERY RESET
BODYFAT START/STOP
MODE
44
Rotary control knob
RESET key
START / STOP key
