Technical Data; Installation Instructions Safety Instructions; Scope Of Delivery; Description - Truma CP plus Installation Instructions Manual

Technical data

Display
Dimensions (L x W x H)
Operating temperature range -25 °C to +60 °C
Storage temperature range -25 °C to +70 °C
Interfaces
CP plus
CP plus CI-BUS
Power supply
Power consumption
Quiescent current
consumption
Weight
Protection class
Protection type
Subject to technical changes.
LCD, monochrome, with
background lighting
92 x 103 x 40 mm
TIN-Bus
TIN-Bus, CI-BUS
8 V – 16.5 V
max. 65 mA (100 % back-
ground lighting) 6.5 mA – 10
mA (Standby)
3 mA (Off)
approx. 100 g
Class III
IP00
Installation instructions
Safety instructions
In-vehicle installations must comply with
the technical and administrative regu-
lations of the respective country of use
(e.g. EN 1648, VDE 0100-721). In other
countries, the relevant regulations must
be observed. National regulations and
rules must be followed.

Scope of delivery

1 Truma CP plus control panel
1 screw (fastening control panel upper section)
4 screws for wall mounting (depending on type)
1 operating instructions
1 installation instructions1
1 connector cable CP plus
1 Mounting frame DBT
To be ordered separately:
Connector cable (TIN bus) available in different lengths.

Description

The Truma CP plus control panel (with polarity reversal protec-
tion) is supplied with voltage via a 12 V connector cable. The
control panel is connected to a Combi CP plus ready heater
and / or an air conditioning system or a Truma iNet Box via a
connector cable (TIN bus). The independently installed CP plus
control panel is suitable for wall mounting on a level surface.
EN 7
