Truma CP plus
Digital Control Panel
If the information in these instructions is not
followed exactly, a fire or explosion may result,
causing property damage, personal injury, or
death.
Do not store or use gasoline or other
flammable vapors and liquids in the vicin-
ity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Evacuate all persons from the vehicle.
• Shut off the gas supply at the gas contain-
er or source.
• Do not touch any electrical switch, or use
any phone or radio in the vehicle.
• Do not start the vehicle's engine or electric
generator.
• Contact the nearest gas supplier or certi-
fied service technician for repairs.
• If you cannot reach a gas supplier or certi-
fied service technician, contact the nearest
fire department.
• Do not turn on the gas supply until the gas
leak(s) has been repaired.
Installation and service must be performed by
a certified service technician, service agency,
or the gas supplier.
Operating instructions
Installation instructions
To be kept in the vehicle.
This document is part of the product.
Page 2
Page 14

Advertisement

Table of Contents
loading

Related Manuals for Truma CP plus

Summary of Contents for Truma CP plus

  • Page 1 Truma CP plus Digital Control Panel If the information in these instructions is not followed exactly, a fire or explosion may result, Operating instructions Page 2 Installation instructions causing property damage, personal injury, or Page 14 death. To be kept in the vehicle.

  • Page 2: Table Of Contents

    Troubleshooting chart (Truma Combi furnace) ....13 Other important information or tips. Safety Behavior and Practices • Use the CP plus control panel only when it is in a technically sound condition. • Have a specialist immediately remedy any malfunctions. Remedy the malfunction...

  • Page 3: Operating Instructions

    Operating Instructions Display and Operating Elements Rotary push button The rotary push button (8) is used to select and change setpoints and parameters; it is then tapped to save the values. Selected menu items flash. Turn clockwise • The menu is scrolled through from left to right •...

  • Page 4: Initial Start-Up

    • After repairs or upgrades, the procedure Functions described in “Initial start-up” has to be repeated. The functions of menu lines (3, 4) of the CP plus • Beim erstmaligen Einschalten des control panel can be selected in any sequence. “Control panel” wird eine angeschlos-...

  • Page 5: Change Room Temperature

    Change room temperature Change hot water level • Use the rotary push button (8) to select the • Use the rotary push button (8) to select the icon in the menu line (3). icon in the menu line (3). • Tap the button to go to the setting level. •...

  • Page 6: Select Energy Mode

    Electricity 850 W EL 2 * Electricity 1700 W * Mixed mode and electricity mode Possible only with Truma Combi eco plus and Truma Combi comfort plus furnaces with electric heating elements. When the furnace is switched on (room tem-...

  • Page 7: Select Fan Speed

    If you park the RV in an enclosed space: • shut off the gas feed to the furnace. • disable the time switch (OFF). • switch the furnace off. (On the Truma CP plus control panel, press the rotary push button (8) for 3 seconds.) •...
  • Page 8 (Truma Combi eco plus or start/end time is reached. Until then, the Truma Combi comfort plus). operating parameters set outside the time switch remain valid.

  • Page 9: Set Clock

    1. Show version number of connected devices Display the version number of furnace and control panel. Set clock 2. Backlighting Change the backlighting of the CP plus control panel in 10 increments. Display 24 h mode Display 12 h mode = a. m. 3. Language = p.

  • Page 10: Display Power Supply 120 Vac

    Newly connected devices are recognized and recorded in the control panel. • Switch on the 12 VDC power supply of the control panel and the furnace. With Truma Combi eco plus and Truma Combi comfort plus, also switch on the 120 VAC power sup- ply (mains supply).

  • Page 11: Warning

    Warning Malfunction This icon indicates that an operating parameter In case of a malfunction, the control panel im- has reached an undefined status. In this case, mediately goes to the menu level “Malfunction” the furnace continues to operate. When the op- and displays the error code of the malfunction.

  • Page 12: Technical Data

    Technical data Display LCD, monochrome, with backlighting Diagonal 3.3 in. (84 mm) Dimensions (L x W x H) 3.62 x 4.06 x 1.58 in. (92 x 103 x 40 mm) Operating temperature range 13 °F to 140 °F (-25 °C to +60 °C) Storage temperature range 13 °F to 158 °F (-25 °C to +70 °C) Interface TIN bus...

  • Page 13: Troubleshooting Chart (Truma Combi Furnace)

    Contact Truma Service. If none of the measures in the troubleshooting chart proves successful or fault codes are displayed that cannot be found in the troubleshooting chart, please contact the Truma Service Center at 1-855-558-7862 or one of our authorized service partners.
  • Page 14 In case you encounter any problems, please contact the Truma Service Center at 855-558-7862 or one of our authorized service partners. For details see www.truma.net. Please have the model number and serial number (on furnace’s type plate) handy when you call.
