Figure 5. Bottom Layout - ST STM32G4 Nucleo-64 User Manual

JP5 5V power
source selection
VREF selection
IDD measurement
Arduino™ connector
Arduino™ connector
ST morpho pin header
UM2505 - Rev 2
JP8
JP6
CN5
CN9
CN10
Figure 5. Bottom layout
CN1 STLINK-V3E
Micro-B USB connector DFU connector
JP1
STLINK-V3E reset
CN2
HW101
board sticker
CN4
MIPI10 connector
JP3 Target reset
CN6
Arduino™ connector
JP7 BOOT0
CN8
Arduino™ connector
CN7
ST morpho pin header
UM2505
PCB layout
page 9/43
