D2.2L G22 Extended Tank (10000018412 - Generac Power Systems D3.4L G16 Extended Tank Installation Manuallines

Installation Drawings
D2.2L G22 Extended Tank (10000018412, page 2 of 2)
101 [4.0]
OUTER TANK EMERGENCY VENT
(2" NPT FEMALE)
660 [26.0]
TYP
620 [24.4]
TYP
487 [19.2]
282 [11.1] 266 [10.5]
TYP
169 [6.7]
216 [8.5]
110 [4.3]
TYP
42
2089 [82.2]
TYP
1386 [54.6]
TYP
1314 [51.7]
TYP
351 [13.8]
INNER TANK NORMAL VENT
227
(2" NPT FEMALE)
[9.0]
INNER TANK EMERGENCY VENT
(2" NPT FEMALE)
FUEL LEVEL
GAUGE/SENDER
FUEL FILL
314 [12.3]
(2" NPT FEMALE)
2160 [85.0]
690 [27.2]
TYP
1216 [47.9]
TYP
1769 [69.6]
TYP
2322 [91.4]
LEFT SIDE VIEW
FUEL RETURN
FUEL SUPPLY
CUSTOMER OPTION
(2" NPT FEMALE)
62 [2.5]
TOP VIEW
TYP
2424 [95.4]
OUTER TANK LEAK DETECTOR
HIGH AND
LOW VOLTAGE
STUB-UP AREA 786 [30.9]
717 [28.2]
125 [4.9]
STUB-UP
AREA
38
[1.5]
51
[2.0]
125 [4.9]
STUB-UP
253
AREA
[10.0]
438 [17.2]
291 [11.5]
FUEL TANK
HEIGHT
19 [.7]
TYP
TITLE
Installation Guidelines for Protector Diesel Generators
FUEL TANK
TOTAL CAPACITY 233 [61]
USABLE CAPACITY 215 [57]
CAPACITY: LITER [GALLON]
DIMENSIONS: MM [INCH]
NOTE: STUB-UP AREA FOR HIGH
AND LOW VOLTAGE CONNECTIONS,
CIRCUIT BREAKER, NEUTRAL AND
CUSTOMER CONNECTION OPENING.
850 [33.5]
REMOVABLE
STUB-UP COVER
SEE NOTE 4
16.7 [0.66]
MOUNTING HOLES
(10 PLACES) SEE
NOTE 9
851 [33.5]
MOUNTING CENTERS
TYP
888 [35.0]
REAR VIEW
