Section 8: Installation Drawings

D2.5L G2 Single Wall (10000022175, page 1 of 2)
RADIATOR/EXHAUST
DISCHARGE AIR
(BOTH SIDES)
RADIATOR/EXHAUST
DISCHARGE AIR
2" O.D.
EXHAUST
OUTLET
212 [8.4]
110 [4.3]
RADIATOR/EXHAUST
DISCHARGE AIR
OPEN PUNCHED LOUVERS TYPICAL
ON BOTH SIDES OF FUEL TANK
VENTILATION DUCT TO PROVIDE
ADEQUATE CROSS-FLOW OF AIR
VENTILATION
EXHAUST MUFFLER
ENCLOSED WITHIN
GENERATOR ENCLOSURE
Installation Guidelines for Protector Diesel Generators
SERVICE ITEM
OIL FILL CAP
739 [29.1]
CENTER OF GRAVITY
OIL DIP STICK
OIL DRAIN HOSE
AIR INTAKE
RADIATOR DRAIN HOSE
(BOTH SIDES)
COOLANT RECOVERY BOTTLE
RADIATOR FILL CAP ACCESS
AIR CLEANER ELEMENT
REFERENCE OWNERS MANUAL FOR PERIODIC
REPLACEMENT PART LISTINGS
REMOVE COVER FOR
BATTERY 12 VOLT
ACCESS TO RADIATOR
NEGATIVE GROUND
FILL CAP
TOP VIEW
ENCLOSURE PANEL MUST BE
REMOVED TO FACILITATE
631 [24.8]
BATTERY INSTALLATION AND
DOOR TYP
REMOVAL
LEFT SIDE VIEW
2.5L WEIGHT DATA WITH EMPTY BASETANK
(SEE NOTE 5)
RIGHT SIDE
GENERATOR AS SHOWN
RIGHT SIDE
WITH WOODEN SHIPPING SKID
OIL FILTER RIGHT SIDE
LEFT SIDE
WEIGHT: KG [LBS]
LEFT SIDE DIMENSIONS: MM [INCH]
LEFT SIDE
ROOF
LEFT SIDE
MUFFLER FRONT
FAN BELT EITHER SIDE
BATTERY LEFT SIDE
REAR ENCLOSURE
COVER PANEL
SEE NOTE 4
CUSTOMER ACCESS
ASSEMBLY, CONTROL
PANEL ACCESS,
BATTERY CHARGER
LOCATED WITHIN
SEE NOTE 4
1238 [48.7]
OVERALL
HEIGHT
CIRCUIT BREAKER
SEE NOTE 3
REMOVABLE
STUB-UP COVER
SEE NOTE 4
776 [30.6]
OVERALL WIDTH
REAR VIEW
NOTES:
1. MINIMUM RECOMMENDED CONCRETE PAD SIZE: 1092 (43") WIDE X 1887 (74.3") LONG.
622 [1372]
REFERENCE INSTALLATION GUIDE SUPPLIED WITH UNIT FOR CONCRETE PAD GUIDELINES.
661 [1457]
2. ALLOW SUFFICIENT ROOM ON ALL SIDES OF THE GENERATOR FOR MAINTENANCE
AND SERVICING. THIS UNIT MUST BE INSTALLED IN ACCORDANCE WITH CURRENT
APPLICABLE NFPA 37 AND NFPA 70 STANDARDS AS WELL AS ANY OTHER FEDERAL,
STATE, AND LOCAL CODES.
3. CONTROL PANEL / CIRCUIT BREAKER INFORMATION:
- SEE SPECIFICATION SHEET OR OWNERS MANUAL
- ACCESSIBLE THROUGH CUSTOMER ACCESS ASSEMBLY DOOR ON REAR OF GENERATOR.
4. REMOVE THE REAR STUB-UP AND REAR ENCLOSURE COVER PANEL TO ACCESS
THE STUB-UP AREAS AS FOLLOWS:
- HIGH VOLTAGE CONNECTION INCLUDING AC LOAD LEAD CONDUIT CONNECTION,
NEUTRAL CONNECTION, AND BATTERY CHARGER 120 VOLT AC (0.5 AMP MAX) CONNECTION.
- LOW VOLTAGE CONNECTION INCLUDING TRANSFER SWITCH CONTROL WIRES
AND ACCESSORY RELAY CONNECTION (QTY 4)
5. CENTER OF GRAVITY AND WEIGHT MAY CHANGE DUE TO UNIT OPTIONS.
6. BOTTOM OF GENERATOR SET MUST BE ENCLOSED TO PREVENT PEST INTRUSION AND
RECIRCULATION OF DISCHARGE AIR AND/OR IMPROPER COOLING AIR FLOW.
7. REFERENCE OWNERS MANUAL FOR LIFTING WARNINGS.
8. MOUNTING BOLTS OR STUDS TO MOUNTING SURFACE SHALL BE 5/8-11 GRADE 5
(USE STANDARD SAE TORQUE SPECS)
9. MUST ALLOW FREE FLOW OF INTAKE AIR, DISCHARGE AIR AND EXHAUST. SEE SPEC
SHEET FOR MINIMUM AIR FLOW AND MAXIMUM RESTRICTION REQUIREMENTS.
10. GENERATOR MUST BE INSTALLED SUCH THAT FRESH COOLING AIR IS AVAILABLE
AND THAT DISCHARGE AIR FROM RADIATOR IS NOT RECIRCULATED.
VISE ACTION LATCH,
ONE PER DOOR, ONE
LIFT-OFF DOOR PER
SIDE OF GENERATOR
303 [11.9]
182 1065 [41.9]
[7.2]
OVERALL LENGTH
LIFTING PROVISION (4 PLACES)
SEE NOTES 5, 7 AND CENTER
RIGHT SIDE VIEW
OF GRAVITY DIMENSIONS
Installation Drawings
1582 [62.3]
