Installation Drawings
D2.5L G2 Single Wall (10000022175, page 2 of 2)
787 [31.0]
691 [27.2]
446 [17.5]
625 [24.6]
TYP
151 [5.9]
851 [33.5]
REMOVABLE COVER
112 [4.4]
TYP
792 [31.2]
TYP
34
FUEL FILL
(2" NPT FEMALE)
1120 [44.1]
FUEL LEVEL
1008 [39.7]
GAUGE/SENDER
EMERGENCY VENT
(2" NPT FEMALE)
FUEL SUPPLY
40 [1.6]
1347 [53.0]
TOP VIEW
1472 [57.9]
TYP
1584 [62.4]
LEFT SIDE VIEW
NORMAL VENT
(2" NPT FEMALE)
HIGH AND LOW
674 [26.5]
VOLTAGE
STUB-UP AREA
105 [4.1]
*STUB-UP
AREA
9
[.4]
51
[2.0]
100 [3.9]
*STUB-UP
AREA
224
[8.8]
251 [9.9]
FUEL TANK
HEIGHT
FUEL TANK
TOTAL CAPACITY 169 [44]
USABLE CAPACITY 151 [40]
CAPACITY: LITER [GALLON]
DIMENSIONS: MM [INCH]
*NOTE: STUB-UP AREA FOR HIGH
AND LOW VOLTAGE CONNECTIONS,
CIRCUIT BREAKER, NEUTRAL AND
CUSTOMER CONNECTION OPENING.
738 [29.1]
354 [13.9]
19 739 [29.1]
[.7] MOUNTING CENTERS
TYP
776 [30.6]
REAR VIEW
Installation Guidelines for Protector Diesel Generators
REMOVABLE STUB-UP
COVER
SEE NOTE 4
16.66 [0.66]
MOUNTING HOLES
(6 PLACES)
SEE NOTE 8
