D3.4L G16 - 132 Gal Tank (10000043316 - Generac Power Systems D3.4L G16 Extended Tank Installation Manuallines

Installation Drawings
D3.4L G16 – 132 Gal Tank (10000043316, page 2 of 2)
376.5 [14.8]
314 [12.4]
246.5 [9.7]
116.6 [4.6]
OUTER TANK EMERGENCY VENT
(3" NPT FEMALE)
714.9 [28.1]
657.9 [25.9]
TYP
484.7 [19.1]
279.9 [11.0]
263.9 [10.4]
TYP
166.9 [6.6]
110 [4.3]
TYP
50
INNER TANK NORMAL VENT
(3" NPT FEMALE)
INNER TANK EMERGENCY VENT
(3" NPT FEMALE)
FUEL LEVEL OUTER TANK
GAUGE/SENDER LEAK DETECTOR
FUEL FILL
CUSTOMER OPTION
(3" NPT FEMALE)
(3" NPT FEMALE)
FUEL RETURN
246.5 [9.7]
FUEL SUPPLY
1307.6 [51.5]
1418.4 [55.8]
2088.4 [82.2]
TYP
62.4 [2.5]
2159.6 [85.0]
TOP VIEW
690 [27.2]
TYP
1216 [47.9]
TYP
1769 [69.6]
TYP
2322 [91.4]
TYP
2423.9 [95.4]
LEFT SIDE VIEW
HIGH AND
LOW VOLTAGE
STUB-UP AREA
786 [30.9]
125 [4.9]
*STUB-UP
AREA
38 [1.5]
51.1 [2.0]
125 [4.9]
*STUB-UP
AREA
253.3 [10.0]
529.3 [20.8]
632 [24.9]
FUEL TANK
HEIGHT
18.5 [.7]
TYP
Installation Guidelines for Protector Diesel Generators
FUEL TANK
TOTAL CAPACITY 524 [138.5]
USABLE CAPACITY 500 [132]
CAPACITY: LITER [GALLONS]
DIMENSIONS: MM [INCH]
THIS TANK IS LISTED TO UL142 AND ULC5601
*NOTE: STUB-UP AREA FOR HIGH AND LOW
VOLTAGE CONNECTIONS, CIRCUIT BREAKER,
NEUTRAL AND CUSTOMER CONNECTION OPENING.
850.1 [33.5]
REAR TANK
COVER PANEL
SEE NOTE 4
16.7 [.66] MOUNTING HOLES
(10 PLACES)
851.1 [33.5]
MOUNTING CENTERS
TYP
SEE NOTE 9
888.1 [35.0]
REAR VIEW
TITLE
