Auxiliary shutdown switches are not intended to be a pri-
mary means to shut down generator under normal oper-
ating conditions. Accidental activation of an auxiliary
shutdown switch will prevent generator from operating
during a power outage.

Checking Automatic Operation

Proceed as follows to check system for correct automatic
operation:
1. Verify generator is in OFF mode. Red LED above
OFF on control panel illuminates to verify system is
OFF.
2. Install front cover over transfer switch.
3. Turn on utility power supply to transfer switch,
using the means provided (such as a utility main
line circuit breaker).
NOTE: Transfer switch will transfer to utility position.
4. Set MLCB on generator control panel ON
(CLOSED).
5. Verify both auxiliary shutdown switches are ON (I).
6. Press AUTO on control panel. System is now
ready for automatic operation.
7. Turn off utility power supply to transfer switch.
With generator ready for automatic operation, engine will
crank and start when utility source power is turned off
after a 10 second delay (factory default setting). After
starting, transfer switch connects load circuits to standby
side. Allow system to operate through entire automatic
sequence of operation.
With generator running and loads powered by generator
AC output, turn on utility power supply to transfer switch.
System transfers back to utility position and then runs
through cool down cycle and shuts down.

Installation Summary

1. Verify installation has been performed correctly as
outlined by the manufacturer and that it meets all
applicable laws and codes.
2. Test and verify correct operation of the system as
outlined in the appropriate installation and owner's
manuals.
3. Educate end-user on correct operation, mainte-
nance, and service call procedures.
Installation Guidelines for Protector Diesel Generators
Shutting Generator Down While
Under Load or During a Utility Outage
DANGER
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
IMPORTANT NOTE: To avoid equipment damage,
follow these steps, in order, during utility outages.
Shutdowns may be required during utility outages to
perform routine maintenance or to conserve fuel.
To turn generator OFF:
1. Set main utility disconnect to OFF (OPEN).
2. Set generator MLCB (generator disconnect) to
OFF (OPEN).
3. Allow generator to run for cool-down for approxi-
mately one minute.
4. Set generator to OFF at the controller.
5. Remove 7.5A fuse from controller.
To turn generator back ON:
1. Install 7.5A fuse in controller.
2. Verify generator MLCB (generator disconnect) is
OFF (OPEN).
3. Set generator to AUTO mode at the controller.
4. Generator will start and run. Allow generator to run
and warm up for a few minutes.
5. Set MLCB (generator
(CLOSED).
6. Set main utility disconnect to ON (CLOSED).
The system now operates in automatic mode.
Operational Checks
(000191)
disconnect) to ON
