Intended use

Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations and
standards applicable for use in industry and trade. It may only be used for the welding
procedures indicated at the rating plate. Hazards may arise for persons, animals and
material objects if the equipment is not used correctly. No liability is accepted for any
damages arising from improper usage!
• The equipment must only be used in line with its designated purpose and by trained or
expert personnel!
• Do not improperly modify or convert the equipment!
3.1

Applications

Device control of multi-process welding machines for arc welding covering the following welding proce-
dures:
Machine series
Titan XQ / XQ C
Titan XQ AC
3.2

Use and operation solely with the following machines

The following system components can be combined:
This description may be applied only to machines with the Expert XQ 2.0 machine control.
Machine control
Description
3.3

Documents which also apply

• Operating instructions for the connected welding machines
• Documents of the optional expansions
3.4

Software version

These instructions apply to the following software version:
2.0.D.0
The machine control software version is shown on the screen during the start
process > see 4.3.3 chapter.
099-00L105-EW501
07.06.2019
Main procedure for MIG/MAG welding
Standard arc Pulsed arc
Expert XQ 2.0
No network connection
WARNING
Secondary process
Expert XQ 2.0 LG Expert XQ 2.0 WLG
Version with LAN Version with Wi-Fi and LAN
Intended use
Applications
