5.4.4.4

Special parameter

The special parameters of the wire feeder control are used to customize the machine function configurati-
on.
The number of selectable special parameters can deviate between the machine controls used in the
welding system.
It may be required to restart the machine in order to apply a parameter change.
Systems with two wire feeder controls show the parameters of the active wire feeder only (special para-
meter U1 or special parameter U2).
Menu i-
tem/parameter
P1
P2
P3
P7
P8
P9
P11
P12
P13
P14
P16
P17
P23
099-00L105-EW501
07.06.2019
Value Comment
1-0 Wire inching / wire return ramp time
0 =-------- normal inching (10 s ramp time)
1 =-------- fast inching (3 s ramp time) (ex works)
0-1 Block program "0"
0 =-------- Enabled (ex works)
1 =-------- P0 blocked
0-1 Display mode for Up/Down welding torch with one-digit 7-segment
display (two keys)
0 =-------- Normal display (ex works) program number/welding power
1 =-------- Display toggles between program number/welding type
0-1 Correction operation, limit value setting
0 =-------- Correction operation switched off (ex works)
1 =-------- Correction operation switched on
0-1 Program switching with standard welding torch
0 =-------- No program switching (ex works)
1 =-------- Special latched
2 =-------- Special latched (n-cycle active)
0-1 Tapping start for latched and special latched operation
0 =-------- no 4-cycle inching start
1 =-------- 4-cycle inching start possible (ex works)
0-1 Special latched tapping time
0 =-------- Tapping function switched off.
1 =-------- 300 ms (ex works)
2 =-------- 600 ms
1-2 JOB list switching
1 =-------- Real JOB list (ex works)
2 =-------- Real JOB list and JOB switching activated via accessories
129 Lower limit remote JOB switching
JOB range of the function torches (MT PC2, PM 2U/D, PM RD2)
Lower limit: 129 (ex works)
169 Upper limit remote JOB switching
JOB range of the function torches (MT PC2, PM 2U/D, PM RD2)
Upper limit: 169 (ex works)
0-1 JOB batch mode
0 =-------- Block JOB mode not enabled (ex works)
1 =-------- Block JOB mode enabled
0-1 Program selection with standard torch trigger
0 =-------- No program selection (ex works)
1 =-------- Program selection possible
0-1 Program settings for relative programs
0 =-------- Combined setting of relative programs possible (ex works).
1 =-------- Individual setting of relative programs possible.
Operating the machine control
(0–9)
Machine configuration (system)
23
