- Page 1 Operating instructions Control T4.03 - Tetrix DC Comfort 2.0 (Tetrix 230) 099-00T403-EW501 Observe additional system documents! 14.07.2020...
- Page 2 +49 2680 181-0. A list of authorised sales partners can be found at www.ewm-group.com/en/specialist-dealers. Liability relating to the operation of this equipment is restricted solely to the function of the equipment. No other form of liability, regardless of type, shall be accepted.
-
Page 3: Table Of Contents
Contents Notes on using these operating instructions Contents 1 Contents ..............................3 2 For your safety ............................5 Notes on using these operating instructions .................. 5 Explanation of icons ........................5 Part of the complete documentation ....................6 3 Intended use ............................7 Use and operation solely with the following machines .............. - Page 4 Contents Notes on using these operating instructions 5.2.2.1 Hotstart current ....................37 5.2.2.2 Hotstart time ....................37 5.2.3 Antistick ......................... 37 5.2.4 Average value pulse welding ..................38 Power-saving mode (Standby) ..................... 38 Access control ..........................39 Voltage reducing device ....................... 39 Machine configuration menu ......................
-
Page 5: For Your Safety
For your safety Notes on using these operating instructions For your safety Notes on using these operating instructions DANGER Working or operating procedures which must be closely observed to prevent imminent serious and even fatal injuries. • Safety notes include the "DANGER" keyword in the heading with a general warning symbol. •... -
Page 6: Part Of The Complete Documentation
For your safety Part of the complete documentation Symbol Description Symbol Description Output Signal light lights up in red Time representation (e.g.: wait 4 s / Signal light flashes red actuate) Interruption in the menu display (other setting options possible) Tool not required/do not use Tool required/use Part of the complete documentation... -
Page 7: Intended Use
• Do not improperly modify or convert the equipment! Use and operation solely with the following machines • Tetrix 230 Comfort 2.0 (T4.03) Documents which also apply • Operating instructions for the connected welding machines • Documents of the optional expansions... -
Page 8: Machine Control - Operating Elements
Machine control – Operating elements Overview of control sections Machine control – Operating elements Overview of control sections For description purposes, the machine control has been divided into two sections (A, B) to ensure maximum clarity. The setting ranges for the parameter values are summarised in the parameter overview section >... -
Page 9: Control Section A
Machine control – Operating elements Overview of control sections 4.1.1 Control section A Figure 4-2 Item Symbol Description Welding data display (3-digit) Displays the welding parameters and the corresponding values > see 4.2 chapter Gas test push-button > see 5.1.1 chapter Operating mode >... - Page 10 Machine control – Operating elements Overview of control sections Item Symbol Description Coolant fault signal light Signals pressure loss or low coolant level in the coolant circuit. Voltage reduction device (VRD) signal light > see 5.5 chapter Signal light Status display Hold After each completed welding task, the last values used in the welding process for the welding current and welding voltage are shown on the displays, and the signal light will...
-
Page 11: Control Section B
Machine control – Operating elements Overview of control sections 4.1.2 Control section B Figure 4-3 Item Symbol Description Parameter selection push-button, left The welding sequence parameters are selected one after another in an anti-clockwise direction. For control systems without this button settings are done exclusively via the control button. -
Page 12: Machine Display
Machine control – Operating elements Machine display Item Symbol Description signal light AC frequency (TIG, JOBs 1–7)/pulse frequency (TIG, average value pulsing)/pulse frequency (MMA) Machine display The following welding parameters can be displayed before (nominal values), during (actual values) or af- ter welding (hold values): Parameter Before welding... -
Page 13: Setting Advanced Welding Parameters (Expert Menu)
Machine control – Operating elements Operating the machine control Display Meaning Factory setting (example value = 20) Parameter is set to optimum value Decrease the parameter value To return to the factory settings. 4.3.4 Setting advanced welding parameters (Expert menu) The Expert menu contains functions and parameters which cannot be set directly in the machine control or which do not need to be et on a regular basis. -
Page 14: Functional Characteristics
Functional characteristics TIG welding Functional characteristics TIG welding 5.1.1 Gas test – setting the shielding gas volume • Slowly open the gas cylinder valve. • Open the pressure regulator. • Switch on the power source at the main switch. • Set the relevant gas quantity for the application on the pressure regulator. -
Page 15: Welding Task Selection
Functional characteristics TIG welding 5.1.2 Welding task selection The setting of the tungsten electrode diameter has a direct influence on the machine functionality, TIG ig- nition behaviour and minimum current limits. The ignition energy is controlled by the set electrode diame- ter. -
Page 16: Arc Ignition
Functional characteristics TIG welding 5.1.3 Arc ignition To change the ignition type, use parameter to switch between HF start ( ) and lift arc ( ) in the Expert menu > see 5.1.9 chapter. 5.1.3.1 HF ignition Figure 5-3 The arc is started without contact from high-voltage ignition pulses. a) Position the welding torch in welding position over the workpiece (distance between the electrode tip and workpiece should be approx. -
Page 17: Operating Modes (Functional Sequences)
Functional characteristics TIG welding 5.1.4 Operating modes (functional sequences) 5.1.4.1 Explanation of symbols Symbol Meaning Press torch trigger 1 Release torch trigger 1 Current Time Gas pre-flow Ignition current Up-slope time Spot time Main current (minimum to maximum current) Secondary current AMP% Pulse time Pulse pause time... -
Page 18: Non-Latched Mode
Functional characteristics TIG welding 5.1.4.2 Non-latched mode Selection Figure 5-5 Sequence Figure 5-6 1st cycle: • Press torch trigger 1 and hold down. • Gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece. The arc ignites. •... -
Page 19: Latched Mode
Functional characteristics TIG welding 5.1.4.3 Latched mode Selection Figure 5-7 Sequence Figure 5-8 099-00T403-EW501 14.07.2020... -
Page 20: Spotarc
Functional characteristics TIG welding cycle • Press torch trigger 1; gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece. The arc ignites. • Welding current flows and immediately assumes the set ignition current (search arc at minimum setting). - Page 21 Functional characteristics TIG welding Figure 5-10 As an example the process is shown with HF ignition. Arc ignition with lift arc is also possible, how- ever > see 5.1.3 chapter. Sequence: • Press torch trigger and hold down. • The gas pre-flow time elapses. •...
-
Page 22: Spotmatic
Functional characteristics TIG welding 5.1.4.5 spotmatic In contrast to the spotArc operating mode, the arc is not ignited by pressing the torch trigger as is usual, but by briefly touching the tungsten electrode against the workpiece. The torch trigger is used for welding process activation. -
Page 23: Tig Activarc Welding
5.1.5 TIG activArc welding The EWM activArc process, thanks to the highly dynamic controller system, ensures that the power sup- plied is kept virtually constant in the event of changes in the distance between the welding torch and the weld pool, e.g. during manual welding. Voltage losses as a result of a shortening of the distance between the torch and molten pool are compensated by a current rise (ampere per volt - A/V), and vice versa. -
Page 24: Pulse Welding
Functional characteristics TIG welding 5.1.7 Pulse welding The following pulse types can be selected: • Automated pulsing • Thermal pulsing • Metallurgical pulsing • Average value pulsing 5.1.7.1 Automated pulses The automated pulsing pulse variant is only activated for DC welding in combination with the spotArc ope- rating mode. -
Page 25: Pulsed Welding In The Upslope And Downslope Phases
Functional characteristics TIG welding Pulse time setting EXIT Figure 5-17 Pulse pause setting EXIT Figure 5-18 5.1.7.3 Pulsed welding in the upslope and downslope phases The pulse function can also be deactivated if necessary during the up-slope and down-slope phases (parameter ) >... -
Page 26: Average Value Pulse Welding
Functional characteristics TIG welding 5.1.7.4 Average value pulse welding A special feature with average value pulses is that the power source will always maintain the preset average value. This makes this method especially suitable for welding according to welding procedure specifications. -
Page 27: Welding Torch (Operating Variants)
Functional characteristics TIG welding Balance setting EXIT Figure 5-23 Frequency setting EXIT Figure 5-24 5.1.8 Welding torch (operating variants) Different torch versions can be used with this machine. Functions on the operating elements, such as torch triggers (BRT), rockers or potentiometers, can be modified individually via torch modes. -
Page 28: Up/Down Speed
Functional characteristics TIG welding 5.1.8.3 Up/down speed Functionality Press and hold the up push-button: Increase current up to the maximum value (main current) set in the power source. Press and hold the down push-button: Decrease current to the minimum value. Use the machine configuration menu >... -
Page 29: Standard Tig Torch (5-Pole)
Functional characteristics TIG welding 5.1.8.5 Standard TIG torch (5-pole) Standard torch with one torch trigger Operating ele- Figure Explanation of symbols ments BRT1 = torch trigger 1 (welding current on/off; secondary cur- rent via tapping function) Functions Mode Operating ele- ments Welding current on/off (ex works) - Page 30 Functional characteristics TIG welding Standard torch with one rocker (rocker, two torch triggers) Figure Operating ele- Explanation of symbols ments BRT 1 = torch trigger 1 BRT 2 = torch trigger 2 Operating ele- Functions Mode ments Welding current on/off Secondary current (ex works) Secondary current (tapping function)
-
Page 31: Tig Up/Down Torch (8-Pole)
Functional characteristics TIG welding 5.1.8.6 TIG up/down torch (8-pole) Up/down torch with one torch trigger Operating ele- Figure Explanation of symbols ments BRT 1 = torch trigger 1 Operating ele- Functions Mode ments Welding current on/off Secondary current (tapping function) )/(latched operating mode) (ex works) Increase welding current (up function... - Page 32 Functional characteristics TIG welding Up/down torch with two torch triggers Figure Operating ele- Explanation of symbols ments BRT 1 = torch trigger 1 (left) BRT 2 = torch trigger 2 (right) Functions Mode Operating ele- ments Welding current on/off Secondary current Secondary current (tapping function) )/(latched operating mode) (ex works)
-
Page 33: Potentiometer Torch (8-Pole)
Functional characteristics TIG welding 5.1.8.7 Potentiometer torch (8-pole) The welding machine needs to be configured for operation with a potentiometer torch > see 5.1.8.8 chapter. Potentiometer torch with one torch trigger Figure Operating ele- Explanation of symbols ments BRT 1 = torch trigger 1 Operating ele- Functions Mode... -
Page 34: Configuring The Tig Potentiometer Torch Connection
Functional characteristics TIG welding 5.1.8.8 Configuring the TIG potentiometer torch connection DANGER Risk of injury due to electrical voltage after switching off! Working on an open machine can lead to fatal injuries! Capacitors are loaded with electrical voltage during operation. Voltage remains present for up to four minutes after the mains plug is removed. -
Page 35: Expert Menu (Tig)
Functional characteristics TIG welding Functions Mode Operating ele- ments Welding current on/off TT 1 Secondary current TT 2 Secondary current (tapping function) TT 1 (tapping) (ex works) Increase welding current (up function) TT 3 Reduce welding current (down function) TT 4 Welding current on/off TT 1 Secondary current... -
Page 36: Mma Welding
Functional characteristics MMA welding Display Setting/selection Ignition type (TIG) ------- HF start active (ex works) ------ Lift arc ignition active MMA welding 5.2.1 Welding task selection It is only possible to change the basic parameters when no welding current is flowing and any possible access control is disabled >... -
Page 37: Hotstart Current
Functional characteristics MMA welding 5.2.2.1 Hotstart current EXIT Figure 5-29 5.2.2.2 Hotstart time EXIT Figure 5-30 5.2.3 Antistick The Antistick feature prevents the electrode from annealing. Should the electrode stick, the machine automatically switches to the minimum current within approx. one second. This prevents the electrode from annealing. -
Page 38: Average Value Pulse Welding
Functional characteristics Power-saving mode (Standby) 5.2.4 Average value pulse welding With average value pulsing, two currents are periodically toggled. The user can adjust the welding current (average current value AMP), pulse current Ipuls (parameter ), balance and frequency to the welding task. -
Page 39: Access Control
Functional characteristics Access control Access control The machine control can be locked to secure it against unauthorised or unintentional adjustment. The ac- cess block has the following effect: • The parameters and their settings in the machine configuration menu, Expert menu and operation se- quence can only be viewed but not changed. -
Page 40: Machine Configuration Menu
Functional characteristics Machine configuration menu Machine configuration menu Basic machine settings are defined in the machine configuration menu. 5.6.1 Selecting, changing and saving parameters ENTER EXIT NAVIGATION Figure 5-34 099-00T403-EW501 14.07.2020... - Page 41 Functional characteristics Machine configuration menu Display Setting/selection Exit the menu Exit Torch configuration menu Set welding torch functions Torch mode (ex works 1) > see 5.1.8.2 chapter Up/down speed > see 5.1.8.3 chapter Increase value > rapid current change Decrease value > slow current change Current jump >...
- Page 42 Functional characteristics Machine configuration menu Display Setting/selection Error Error message after entering an incorrect machine code Access control – access code Setting: 000 to 999 (000 ex works) Machine code Querying the three-digit machine code (000 to 999), user input Error Error message after entering an incorrect machine code New machine code...
-
Page 43: Rectifying Faults
Rectifying faults Error messages (power source) Rectifying faults All products are subject to rigorous production checks and final checks. If, despite this, something fails to work at any time, please check the product using the following flowchart. If none of the fault rectification procedures described leads to the correct functioning of the product, please inform your authorised dea- ler. -
Page 44: Dynamic Power Adjustment
Rectifying faults Dynamic power adjustment Dynamic power adjustment This requires use of the appropriate mains fuse. Observe mains fuse specification! This function enables aligning the machine to the mains connection fusing to avoid continuous tripping of the mains fuse. The maximum power input of the machine is limited by an exemplary value for the exis- ting mains fuse (several levels available). -
Page 45: Appendix
Appendix Parameter overview – setting ranges Appendix Parameter overview – setting ranges 7.1.1 TIG welding Name Display Setting range Main current AMP, depending on power source Gas pre-flow time Ignition current, percentage of AMP Ignition current, absolute, depending on power source Start time 0,01 0,01... -
Page 46: Mma Welding
Appendix Parameter overview – setting ranges Name Display Setting range Amplitude balance [1], [2], [3] Dynamic power adjustment Machines with control Comfort 2.0. Machines for AC welding (AC). Machine series Tetrix 300. Machine series Tetrix 230. 7.1.2 MMA welding Name Display Setting range Main current AMP, depending on power source... -
Page 47: Searching For A Dealer
