4.3.2.1

Main screen variants

You can select the required variant (type of main screen) in the Machine configuration (system)
menu > see 5.4.6 chapter.
4.3.3

Initial screen

During the start process the control name, machine software version and selected language are shown
on the screen.
Item Symbol
1
2
3
4
5
099-00L105-EW501
07.06.2019
Main screen type 1
Main screen type 3
Description 0
Machine control name
Progress bar
Shows the load progress during the start process.
Advanced settings
Display and setting of advanced system parameters > see 4.3.3.1 chapter
Indication of the system language selected
The system language can be changed during the start process > see 4.3.3.2 chapter.
Control software version
Main screen type 2 (ex works)
Figure 4-3
Figure 4-4
Quick overview
Machine display
