5.6.5.1
Overview of the welding parameter switching options
The user can change the welding parameters of the main programs with the following components.
M3.7 – I/J
Wire feeder control
PC 300.NET
Software
MT Up/Down
Welding torch
MT 2 Up/Down
Welding torch
MT PC 1
Welding torch
MT PC 2
Welding torch
PM 2 Up/Down
Welding torch
PM RD 2
Welding torch
PM RD 3
Welding torch
Example 1: Welding workpieces with different sheet metal thicknesses (non-latched)
099-00L105-EW501
07.06.2019
Operating the machine control
Welding task administration (Menu)
P0
P1-15
P0
P1-15
P0
P1-9
P0
P1-15
P0
P1-15
P0
P1-15
P0
P1-15
P0
P1-15
P0
P1-15
Figure 5-21
43
