Parts List - Multipress - Maxxus Multipress 10.1 Installation Manual

Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are bulky and
heavy.
Check that all the parts and fixing materials (screws, nuts, etc.) have been delivered.
Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assembly are not
covered by the warranty or guarantee. Therefore, read through the assembly instructions carefully before you start assem-
bling, follow each assembly step exactly as described and keep to the correct sequence of assembly as instructed.
Assembly of the training device must be carried out thoroughly by an adult person only.
Assemble the training device in a location which is level, clean and clear of obstructions. 2 people are required to carry out
the assembly.
Please be aware a possible risk of injury at the time of assembly and at each time of using this device exists. For this rea-
son, always be careful and thorough in your actions when assembling this device.
Make sure that the parts necessary for each stage of assembly are only hand tightened together and only tighten parts
completely when all parts have been fitted together perfectly.
Training can only start when the training device has been fully assembled.
Parts List – Multipress
Part Description
71 Hex. Head Screw M10x75
72 Hook
73 Carabiner Hook
74 Pull Bar, long
75 Pull Grip
77 Dumbbell Bar Holder, fixed
78 Dumbbell Bar Holder, moving
80 Shelf, long
81 Mounting for Leg Stabiliser
82 Leg Holster w. Curved Cushion
83 Threaded Spring Clip Grip
84 Locking Pin Ø10x100
85 Roller Guide
86 Foot, rear
87 Spring plate Ø12
90 Basic Pipe f. Barbell Bar
Assembly – Multipress
Qty
11
2
2
3
1
2
1
1
2
1
1
1
1
1
1
6
1
