Maxxus Multipress 10.1 Installation Manual page 41

Part Description
1 Base Bar, front
2 Base Bar, rear
3 Base Bar
4 Mounting Plate, bent
5 Hexagonal Head Screw
6 Hexagonal Head Screw
7 Mounting Plate, straight
9 Grip Screw with Locking Pin
16 Sliding Carriage
17 Support Tube for Back-Rest
18 Base Frame for Seat Cushion
19 Hexagonal Head Screw
20 Guide Pipe
21 Aluminium Cap, round
29 Back-Rest Cushion
30 Distance Tube
31 Seat Cushion
32 Washer
33 Washer
34 Shaft Pipe for Arm Curler
35 Swivel Bracket for Leg Curler
36 Swivel Bracket for Arm Curler
37 Cross Pipe
38 Safety Split Pin
39 Hexagonal Head Screw
40 Cushion for Arm Curler
42 Distance Tube
47 Round Cushion
48 Cover Plate (large opening)
49 Cover Plate (small opening)
50 Hexagonal Head Screw
51 Stand Pipe
52 Safety Nut
53 Safety Nut
54 Washer
55 Hexagonal Head Screw
56 Headless Screw
59 Safety Split Pin
60 Hexagonal Head Screw
Assembly – Training Bench
Type
41
T3,0x59x140
M10x100
M10x75
T4,0x50x140mm
M18x1.5mm
M8x20
Ø50xØ11x9,5mm
840x330x50mm
Ø16x50mm
370x300x50mm
Ø8
Ø10
Ø25xT2,0x450
Ø10x85
M10x20
Ø25x67
M8x25
M10
M12
Ø12
M12x75
M10x20
Ø10x100
M8x25
Quantity
1
1
1
1
2
2
1
2
1
1
12
2
4
1
2
1
14
10
1
1
ENG
1
3
1
2
1
1
6
6
6
6
1
4
2
4
2
4
1
2
