CHARACTERISTICS:

The HD67716 is a BACnet Master / PROFIBUS Slave - Converter.
They allows the following characteristics:
Up to 512 BACnet objects in reading and 512 objects in writing;
Triple isolation between PROFIBUS - Power Supply, PROFIBUS - BACnet, BACnet - Power Supply;
Two-directional information between PROFIBUS bus and BACnet bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67716 software on your PC in order to perform the following:
Define the parameters of BACnet line;
Define the parameters of PROFIBUS line;
Define the BACnet data that the converter reads;
Define the BACnet data that the converter writes;
Update the device.
ADFweb.com S.r.l.
User Manual BACnet Master / PROFIBUS Slave
Document code: MN67716_ENG Revision 1.001 Page 7 of 28
