In the field "Max Error" the number of consecutive errors that the Master waits before discard the row from the cycle of requests is
defined;
In the field "Position" it is possible to select the position/byte where taking the data from the PROFIBUS array is defined;
The field "Start Bit" is used for the Binary BACnet objects. It is possible to select the bit in the byte from which taking the data;
By checking the field "Swap" it is possible to swap the order of data to write to BACnet slave;
In the field "Mnemonic" a description of the data inserted in the row is defined.
PROFIBUS GSD:
By pressing the "PROFIBUS GSD" button it is possible to save the GSD file for the PROFIBUS side.
With this feature you can save the configuration of the converter of the PROFIBUS side.
Note:
When you import the .gsd file on your Master PROFIBUS it is necessary to add all the modules that are present inside it.
