Peripheral Pin
IC4
U3RX
U4CTS
SDI1
SDI2
Peripheral Pin
INT2 ()
T4CK
IC2
IC5
U1CTS
U2CTS
SS1
Peripheral Pin
INT1 ()
T3CK
IC1
U3CTS
U4RX
U5RX
SS2
OCFA
https://reference.digilentinc.com/reference/microprocessor/basys-mx3/reference-manual?_ga=2.68739409.1349070004.1564406803-1961480359....
Basys MX3 Reference Manual [Reference.Digilentinc]
[pin name]R SFR [pin name]R bits
IC4R
U3RXR
U4CTSR
SDI1R
SDI2R
[pin name]R SFR [pin name]R bits
INT2R
T4CKR
IC2R
IC5R
U1CTSR
U2CTSR
SS1R
[pin name]R SFR [pin name]R bits
INT1R
T3CKR
IC1R
U3CTSR
U4RXR
U5RXR
SS2R
OCFAR
IC4R<3:0>
U3RXR<3:0>
U4CTSR<3:0>
SDI1R<3:0>
SDI2R<3:0>
INT2R<3:0>
T4CKR<3:0>
IC2R<3:0>
IC5R<3:0>
U1CTSR<3:0>
U2CTSR<3:0>
SS1R<3:0>
INT1R<3:0>
T3CKR<3:0>
IC1R<3:0>
U3CTSR<3:0>
U4RXR<3:0>
U5RXR<3:0>
SS2R<3:0>
OCFAR<3:0>
[pin name]R Value to RPn Pin Selection
0100 = RPF0
0101 = RPB1
0110 = RPE5
0111 = RPC13
1000 = RPB3
1001 = Reserved
1010 = RPC4
1011 = RPD15
1100 = RPG0
1101 = RPA15
1110 = RPF2
1111 = RPF7
[pin name]R Value to RPn Pin Selection
0000 = RPD9
0001 = RPG6
0010 = RPB8
0011 = RPB15
0100 = RPD4
0101 = RPB0
0110 = RPE3
0111 = RPB7
1000 = Reserved
1001 = RPF12
1010 = RPD12
1011 = RPF8
1100 = RPC3
1101 = RPE9
1110 = Reserved
1111 = RPB2
[pin name]R Value to RPn Pin Selection
0000 = RPD1
0001 = RPG9
0010 = RPB14
0011 = RPD0
0100 = RPD8
0101 = RPB6
0110 = RPD5
0111 = RPB2
1000 = RPF3
1001 = RPF13
1010 = Reserved
1011 = RPF2
1100 = RPC2
1101 = RPE8
1110 = Reserved
1111 = Reserved
