Connection and regulation of KONTAKT 155/R to CO2 bottle

1. Screw the plastic fittings onto the keg coupler (see picture 5. and 6./ page 4 a 5).
2. Insert the hose 3/8 and 5/16 into the plastic fittings on the keg coupler
(see picture 8. and 9./ page 5).
3. Connect the hose 3/8 and 5/16 with the plastic fittings placed on the cooling machine
according to the description on the label. The label is located above the fittings.
4. Attach the high pressure hose to the CO2 bottle using a cap nut (7.).
5. Put the coupler on the beverage keg and make sure the coupleris in the closed position
(upper position).
6. Open the shut-of valve on the CO2 bottle and set the desired pressure for both lines
using the srews on the top of the machine (No.3). (The pressure setting is displayed on
the manometer of the front side of the cooling machine).
7. Connect the keg using the keg coupler.
25 FLOW TYPE CONTACT COOLER LINDR
