Connection C: using an inbuilt compressor to pressurize (for machines with two dispensing taps)
1. Beverage inlet
2. Air outlet
3. Keg coupler (S-type,
A-type, M-type)
4. Plastic fitting
F 5/8x9.5 mm
5. Plastic fitting
F 5/8x8 mm
6. Plastic fitting
Y 8x8x8 mm
7. Beverge
8. ON/OFF switch for
the compressor
Only for models with built-in air compressor PYGMY 20/K, PYGMY 25/K, PYGMY 30/K profi,
KONTAKT 40/ K, KONTAKT 40/K profi and models GREEN LINE PYGMY 25/ K, KONTAKT
40/K, KONTAKT 70/ K, KONTAKT 155/ K.
The mini air compressor is built into the cooling system. Automatic pressure control is
set to 2.8-3.2 bar. For Kprofi models there is the possibility of continuous pressure control
in the range of 1.0-3.4 bar. The set pressure value is displayed on the manometer in bars.
The compressor can be switched off by the switch itself. The air outlet from the cooler is
closed by a DM 5/16 (8mm) fast fitting and marked AIR. The air compressor is maintenan-
ce-free, equipped with a molecular air intake filter.
ˇ
6.
3.
4.
5.
5.
7.

Built-in air compressor

23
8.
2.
1.
3.
4.
