0x00000020
0x00010000
0x00100000
T
ABLE
T S
IME TAMPS
During data acquisition, the EX1401 returns timestamps along with digitized analog data. The
timestamps are created based on the TimestampSource clock specified in the ReferenceOscillator
interface. When IEEE 1588 synchronized time stamps are desired, the TimestampSource property
must be set to ReferenceOscillatorTimestampSourceSystem. Otherwise, the time returned will be
the time elapsed since the SYNC signal was received.
When measurement data is retrieved, both a timestamp of the data record and a timestamp of trigger
event are returned. The combination of TimeSeconds and TimeFraction parameters indicate the time
of the first data sample in each retrieved data record. The time of trigger event is returned in the
AdditionalData parameter.
Timestamp Source
System (IEEE 1588)
PXIe_CLK100
A D
DDITIONAL ATA
The additional information associated with the data records are returned as a JSON (Java Script
Object Notation) array of name/value pairs:
[[JSON array for channel 1's first record], [JSON array for channel
2's first record], ...]
The JSON object array for each channel is:
[{Object1}, {Object2}, ...]
Each object is a list of name/value pairs:
{name1:value1, name2: value2, ...}
JSON objects can be parsed using the following defined name strings.
88
Open Transducer
ADC Overload
ADC Sync
5-2: I -S
NSTRUMENT PECIFIC
PTP or TAI (International Atomic Time)
Elapsed time from last SYNC
T 5-3: T S
ABLE IMESTAMP OURCE AND
The OTD trickle current is enabled and has caused
the input voltage to rise above the upper limit of the
ADC's valid input range.
The signal is outside of the ADC's valid input range,
either too high or too low.
The channel's ADC has become unsynchronized
from the others in the instrument, likely due to
electrostatic discharge. While this status bit remains
set, the firmware is resynchronizing it.
F S B S
AULT TATUS IT UPPORT
Timestamp value
R
ESOLUTION
EX1401 Instrument Drivers
Resolution
40 ns
40 ns
