download from VTI Instruments online portal (www.vtiinstruments.com) under the specific
product's download page.
The Linux driver (32-bit and 64-bit) is located under <CD-ROM Drive>:\Drivers\Linux
Drivers\Linux EX Series . Open the appropriate zip file in this directory and then run the RPM
Installer. Alternately the instrument drivers for Linux OS are also available for free download from VTI
Instrument website,

Platform/LXISync Instrument Driver Installation

NOTE Complete this step only if the LXISync capabilities of the EX platform are required. If this
driver was installed previously on the host PC, software installation is now complete.
To install the Platform/LXISync Instrument driver, navigate to <CD-ROM Drive>:\LXI
Drivers\EMX Platform Driver, IVI on the CD and run the .msi installer located in this directory.
Please refer to the VTEX Digitizer Driver's online help file for programming guidelines. Additional
information about IVI drivers can be found on the web at http://ivifoundation.org. Information about
the LXI standard and LXI technology can be found at http://www.lxistandard.org.
N C
ETWORK ONFIGURATION
By default, the EX1401 will attempt to locate a DHCP server. If one is found, the IP address assigned
by the DHCP server will be assumed. Otherwise, after a timeout of 20 seconds, the unit will attempt
to obtain an IP address by using Auto IP.
Auto IP is a mechanism for finding an unused IP address in the range 169.254.X.Y where X is in
the range 1 - 254 and Y is in the range 0 - 255. The device will first attempt to obtain the specific
address 169.254.X.Y, where X and Y are the second-to-last and last octets of the device's MAC
address. However, X will be set to 1 if it is 0 in the MAC address, and to 254 if it is 255 in the MAC
address. If this address is already in use, the unit will attempt to obtain other IP addresses in a
pseudorandom fashion until it finds one that is available.
EX1401 Preparation for Use
F 2-5: I D
IGURE NSTRUMENT
