Self-Test

The results of the self-test will show "Passed" or "Failed". Use the web interface for detailed results
of the last self-test.

USB

A USB device screen shows both the unique device name and the volume label. Holding the Menu
button on a USB device screen will safely eject the device.
Each USB device also has a screen for use as a Data Logger. Holding the Menu button on this screen
will cause the instrument to load a stored configuration file from the USB device and start a
measurement. If the stored configuration file specifies, measured data may also be saved to the USB
device during a Data Logger measurement. While a Data Logger measurement is in progress, a
status screen will be displayed.
The status screen shows four items: Measurement State, Acquired Records, Completed Triggers,
and Trigger Time Remaining.
•
Measurement State: This indicates the current state of the measurement's trigger state
machine. Possible values are:
•
Acquired Records: The number of records measured so far this measurement.
•
Completed Triggers: If Trigger Count is finite, the percentage of total triggers completed
so far. If infinite, the number of triggers completed.
EX1401 Basic Operation
Self Test
Hold MENU to start
Self Test
Passed
USB at sda1
SP UFD U3
USB at sda1
Safe to remove
Data Logger: sda1
SP UFD U3
Meas
15% Trigs
o
Idle: Not running
o
Settle: Waiting for digital filters to settle
o
Start: Waiting for the configured Start event to occur
o
ArmWait: Waiting for the configured Arm event to occur
o
TrigWait: Waiting for the configured Trigger event to occur
o
PreTrig: Waiting for pre-trigger samples to be buffered
o
Meas: Measuring data after a trigger
10 recs
1:42m
