EX1401 Operation of Data Logger
o
EX_MEAS_INFO (dataset)
▪
Packet info - The upper 16 bits of the VRT Header word
▪
Packet size - The total number of 32-bit words in the packet
▪
Stream ID - The VRT Stream identifier
▪ OUI - VTI's IEEE Organizationally Unique Identifier
▪
Information class code - The VRT information class identifier
▪
Packet class code - The VRT packet class identifier
▪
Time seconds - The seconds portion of the packet timestamp
▪
Time picoseconds upper - The upper 32 bits of the
picoseconds portion of the packet timestamp
▪
Time picoseconds lower - The lower 32 bits of the
picoseconds portion of the packet timestamp
▪
Context Indicator Field - A mask indicating which items are
included in Context Fields
▪
Context Fields - A list of 32-bit words comprising the data
payload of the context packet
o
EX_MEAS_FLOAT32 (dataset)
▪
Packet info - The upper 16 bits of the VRT Header word
▪
Packet size - The total number of 32-bit words in the packet
▪
Stream ID - The VRT Stream identifier
▪ OUI - VTI's IEEE Organizationally Unique Identifier
▪
Information class code - The VRT information class identifier
▪
Packet class code - The VRT packet class identifier
▪
Time seconds - The seconds portion of the packet timestamp
▪
Time picoseconds upper - The upper 32 bits of the
picoseconds portion of the packet timestamp
▪
Time picoseconds lower - The lower 32 bits of the
picoseconds portion of the packet timestamp
▪
Samples - A list of 32-bit floating point data samples
▪
Trailer - The 32-bit VRT trailer word
o
EX_MEAS_INT32 (dataset)
▪
Packet info - The upper 16 bits of the VRT Header word
▪
Packet size - The total number of 32-bit words in the packet
▪
Stream ID - The VRT Stream identifier
▪ OUI - VTI's IEEE Organizationally Unique Identifier
▪
Information class code - The VRT information class identifier
▪
Packet class code - The VRT packet class identifier
▪
Time seconds - The seconds portion of the packet timestamp
▪
Time picoseconds upper - The upper 32 bits of the
picoseconds portion of the packet timestamp
▪
Time picoseconds lower - The lower 32 bits of the
picoseconds portion of the packet timestamp
▪
Samples - A list of 32-bit integer data samples
▪
Trailer - The 32-bit VRT trailer word
