VTI Instruments Corp.

IPv4 Address

If the device does not have an IPv4 address, the display will show "Network unavailable" instead
of the IPv4 address.

IPv6 Addresses

The IPv6 address screens show one or two addresses on two or three screens. Because an IPv6
address is too large to fit on a screen the addresses are split between the HostID, which is the lower
64-bits, and the Subnet, which is the upper-64 bits. If the device does not have a global IPv6 address,
it will show as "Network unavailable". If IPv6 is disabled, then all IPV6 screens will show "Network
unavailable". Note that the HostID portion is common to both the Local and Global addresses and
so is only displayed once.

MAC Address

LAN Reset

46
IPv4 Address********
10.87.37.24_______
IPv4 Address********
Network unavailable
IPv6 Local Subnet
fe80:0000:0000:0000*
IPv6 HostID
020d:3fff:fe01:1f9c*
IPv6 Global Subnet*
Network unavailable
MAC Address
00:0d:3f:01:1f:9c
LAN Config Reset
Hold MENU to reset
EX1401 Basic Operation
