Specifications - Mircom OpenBAS-HV-NX10 Series Installation Manual

5.0

Specifications

Standards:
Input:
Output:
Power Supply Protection:
Battery:
Relay Outputs 1 and 5:
Relay Outputs 2, 3, 4, 6, 7, 8:
2 Analog Outputs:
8 Universal Inputs:
40 (45)
UL 60730-1
12 Vdc, 360 mA max., or 24 Vdc, 450 mA max.,
or 24 Vac 50/60 Hz, 500 mA max.
12 Vdc, 250 mA max. (when 24V powered)
Resettable Fuse 1.1 A
FDK Corporation ML2430
Type: lithium
Nominal capacity: 100 mAh
Nominal voltage: 3 V
Mircom part number: BT-025
Voltage, current
125 VAC, 5 A
28 VDC, 5 A
Voltage, current
125 VAC, 5 A
125 VAC, 3 A
Analog Output Voltage:
• 0-10 VDC
• 2-10 VDC
• 0-5 VDC
Analog Inputs:
• 0-10 VDC
• 0-5 VDC
• 0.5-4.5 VDC ratiometric
• 0-20 mA
• 4-20 mA
• 1000 Ω temperature sensor
• Thermocouple input with x200 amplifiers
Digital (binary) inputs:
• For dry contacts being fed by 12 VDC
Pulse counters:
• Active PNP 12 VDC
• For dry contacts being fed by 12 VDC
Load Form
General Use NO/NC
Resistive NO/NC
Load Form
Resistive NO
General Use NO
