Information And Tasks While Printing - SINTERIT Lisa Pro Shortened User Manual

11. When the levelling is done and the RECOATER
has returned to its default position, the cleaning
process must be initiated.
• Use a wipe soaked with alcohol (ethanol
or salicylic alcohol 2%) to very carefully clean the
vision windows of the camera and pyrometers.
• Clean the infrared heaters (white and red
ones) by gently blowing on them with clean
compressed air.
12. Ensure that no tools or previous printouts are left
in the printing chamber.
13. Clean any excess powder from the area around
the BEDs, the guide bar and the cables of the
RECOATER, using a paintbrush.
14. Lubricate the plain bearing of the RECOATER with
the included silicone grease, by lubricating the
slide guide rail
15. Press DONE and gently close the Lid.
16. If necessary, connect the nitrogen supply to the
gas input (for more information on this in the full
operating instructions; chapter 9, part B).
17. Press START PRINTING button on the LISA PRO
display and the printing process will start.
18. Upon confirmation, the progress of printing
process will appear on the screen.

4. Information and tasks while printing

1. The main screen of the graphical user interface
displays in real time: the status of the print,
current temperature of the PRINT BED, warming
and cooling states, and the remaining time
of laser sintering.
2. Clicking on the CAMERA button activates the
internal camera view, which will be displayed
for 10 seconds. After that the display will return
to the main screen.
3. During printing, if visible problems appear,
observed by means of the internal camera or
the top vision window, the user can fine tune the
temperature (TEMP +/- 5 [°C]).
10 | Sinterit Lisa PRO USER MANUAL (short version)
.
IMPORTANT!
If the quality of the distributed
powder is unsatisfying, close the
lid and press BACK button on the
LCD screen. Unlock Lid and start
the Leveling process again.
Image 24. Clean the pyrometer screen.
DONE
Image 25. Finalizing preparations for printing screen.
Image 26. Start printing screen.
Image 27. The main screen during printing.
