SINTERIT Lisa Pro Shortened User Manual page 14

7. All remaining unsintered powder from the FEED
BED should be placed into the PRINT BED. Precisely
clean the FEED BED from the remaining unsintered
powder including the BEDs surroundings. This can
be done with the use of a spatula.
SKIP button can be pressed if cleaning process had
been already done.
8. Ensure that the workspace of the RECOATER is not
obstructed and remove all objects from the printer
chamber.
9. Check if all elements are at their default positions
(RECOATER, LASER). Check the tension and
condition of the RECOATER's CABLES. Confirm by
clicking DONE button.
10. PRINT BED MIGHT NOT HAVE BEEN CLEANED
AFTER LAST PRINT message will appear.
All remaining unsintered powder from print
chamber should be removed (Image 39).
11. All remaining powder from the PRINT BED should
be placed into the OVERFLOW BIN, by directing the
powder through a gap located on the right side of
the printer's inner chamber. Thoroughly clean the
PRINT BED from the remaining unsintered powder
including the BEDs surroundings. This can be done
with the use of a spatula (Image 40).
Image 38. Clean PRINT BED screen 1.
12. Remove all objects from the print chamber and
ensure no obstructions are present within the
RECOATER's workspace. Confirm by clicking DONE
button.
After finishing the cleaning process, confirm by
clicking DONE (Image 41).
13. Thoroughly clean all the remaining unsintered
powder from the surroundings. All remaining
powder should be placed into the OVERFLOW
BIN through the gap. Confirm by clicking DONE
(Image 42).
14 | Sinterit Lisa PRO USER MANUAL (short version)
STOP!
For cleaning the guide bar of the RECOATER, it is recommended to use a paintbrush with
a soft bristle (included in the set), or compressed air (when there is no powder inside the
printer). After cleaning, the guide bar of the RECOATER should be lubricated with silicone
oil (included in the accessory kit).
Image 36. Clean FEED BED screen.
Image 37. Removing the powder from the FEED BED.
Image 39. Clean PRINT BED screen 2.
Image 40. Removing powder from PRINT BED
to OVERFLOW BIN.
