User Guide | Intelligent Purger System (IPS 8) for Ammonia - Technical data, installation and use

Technical data

Ordering

20 | BC306932151284en-000101
Supply voltage
Current
Power consumption
Short-circuit current rating
Temperature range ambient
Temperature range transport/storage
Enclosure
Weight
Dimensions (LxWxH)
Purger refrigerant
Max. operating pressure (PS) R452A
System refrigerant
Min. operating pressure R717
Max. operating pressure R717
Operating temperature R717
Unit
Danfoss Intelligent Purger System IPS 8 unit
Accessories/Spare parts
Flange blind blank incl Bolts, nuts and Gaskets*
SV3 Float Valve
ICF 15-4 solenoid, DIN
ICF 15-4 solenoid, ANSI
Welding Flange incl Bolts, nuts and Gaskets
Purger solenoid kit (Armature, tube, Sealing, Orifice, Filter insert)
Solenoid coil, 220 – 230V, 50 HZ for AKV
Solenoid coil, 24V for AKV
PSU, 24V - optional for powering purge points
Restrictor, purge line
Compressor Cranck case heater
Condenser coil assy incl screws
Fan motor for condenser Incl fan grid and screws
Extraction Fan
Air grid with filter (2 pieces)
Pre-programmed MCX 15
Pressure transmitter evaporator, soldered (AKS 32R)
Compressor including Start relay box and Start and Run Capacitor
Compressor Hi-temp sensor
Expansion valve, R452A
Sigth glass
Pressure transmitter - R717, Threaded, AKS2050
Thermostat for crankcase heater control
Temperature sensor - R717, AKS 21M
Pressure switch for Fan
Pressure safety switch
* For closing system flange during system pressure testing
230V AC, 1ph, 50Hz
5.7 A (max. 6.5 A)
max. 1.3 kW
Icc 10kA
-10 °C to +43 °C (14 °F to 109 °F)
-30 °C to +60 °C (-22 °F to 140 °F)
IP55
max. 100 kg (221 lbs)
1051 x 441 x 703 mm (41.4 x 17.4 x 27.7 inches)
R452A 900 gram (31.7 oz)
28 bar (406 psi)
R717
6.5 bar (94 psi)
40 bar (580 psi)
-40 °C to +60 °C (-40 °F to 140 °F)
Accessory Spare part
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
© Danfoss | DCS (ms) | 2019.06
Code number
084H5001
Code
084H5053
027B2023
027L4543
027L4538
084H5055
084H5051
018F6801
018F6757
080Z0055
084H5054
084H5058
084H5059
084H5060
084H5056
084H5057
084H5052
060G3552
123F2126
084N2003
068U3881
014-0191
060G5750
060L111166
084N2003
Contact Danfoss
Contact Danfoss
