Measuring Timing Events - Fourier MultiLogPRO User Manual

Position the cursor in the area you want to zoom into.
Press the two arrow buttons,
You will zoom in around the cursor in a 2:1 ratio.
Press the Escape button

Measuring Timing Events

MultiLogPRO incorporates an accurate Timer module with resolution of 0.1ms. The
timer can measure several types of events triggered by Fourier Systems' photogates:

Time and speed with one photogate

Time and speed between two gates

Time, speed and acceleration between two gates

Stopwatch
To learn more about the different measurement types see page Error! Bookmark
not defined. and page Error! Bookmark not defined..
While in Timer mode MultiLogPRO does not store data. To save timing data in the
computer operate the Timer module via MultiLab.
To learn how to use the timer with MultiLab software please see section 4.9.
To use the photogates together with other sensors operate MultiLogPRO as a data
logger and then analyze the photogate data with the aid of MultiLab's Timing Wizard
(see page Error! Bookmark not defined.).
To perform a timing measurement:
Connect one or two photogates to MultiLogPRO
Use the Forward
the Timing
Press Enter
Fourier Systems Ltd.
16 Hamelacha St., POB 11681, Rosh Ha'ayin 48091,
Tel: +972-3-901-4849, Fax: +972-3-901-4999
www.FourierEdu.com
and Backward
menu
to display the timing menu:
_ _ _ _ _ T I M I N G _ _ _ _ _
 M o d e : T i m e S p e e d
M e a s u r e : I n 1
C a r d w i d t h : 3 0 m m
and , simultaneously.
to zoom out.
arrow buttons to navigate to
