SECTION 7 - OPERATION
each day of that month that the datalogging is running.
If a review of the History Report shows that an
abnormal event occurred on March 3rd at 2:05pm, the
user can import the 20150303.csv file into Excel and
look at the system parameter details leading up to the
2:05pm event.
Follow all Quantech Safety Directives
when inserting or removing the SD card
since the card is located inside the control
cabinet.
To start the Data Logging, insert the SD card into the
SD card slot on the 03478 IPUII board. The label on
the SD card should be facing outwards.
Once the SD card is inserted and the unit is powered
up, press the OPTIONS key. Then press the Down
Arrow key to advance to the DATA LOG TO FLASH-
CARD selection. Next press the Right Arrow key to
select ON then press the ENTER key to start the Data
Log. A 2GB SD card will hold about 8 months worth
of data. A smaller card may be used that will hold less
data but should be tested for compatibility. The con-
troller operating system does not support SD cards
larger than 2GB. When the SD card becomes full, the
oldest date file is automatically deleted and a new day
log file is written in its place.
To stop the data logging and retrieve the SD card, press
the OPTION key and then the Down Arrow key to dis-
play the DATA LOG TO FLASHCARD option and
then use the Right Arrow key to select OFF then press
the ENTER key.
Again, follow the Quantech Safety Directives to stop
the chiller, power off the unit and open the control cab-
inet door to retrieve the SD card.Once inside the con-
trol cabinet, lightly press in on the SD card and then re-
lease the pressure. The SD card should pop out slightly

TABLE 16 - DATA LOGGING

SYS 1
SYS 1
SUCT
DSCH
HOUR MIN SEC
PRESS
PRESS
PSIG
PSIG
0
0
10
82.6
84.4
11
0
15
82.6
84.4
11
22
20
82.6
84.4
11
22
25
82.6
84.4
11
22
30
82.6
84.4
11
22
35
82.5
84.4
108
SYS
SYS
SYS 1
SYS 1
1 SAT
1 OIL
SUCT
SUCT
SUCT
PRESS
TEMP
SHEAT
TEMP
°
°
°
PSIG
F
F
F
84.4
93
77.5
15.5
84.4
93
77.5
15.5
84.4
93
77.5
15.5
84.4
93
77.5
15.5
84.4
93
77.5
15.5
84.4
93
77.4
15.6
to allow removal. You may then copy the files to a PC
for analysis or email the file to someone. The files are
saved as a CSV format which can be read by Excel.
Below is a sample of some of the data imported from
a QTC4 Chiller. Once the file is read in to Excel, you
can hide unrelated columns or plot desired parameters
to analyze the data.

Invalid Number of Compressors Warning

The INVALID NUMBER OF COMPRESSORS
SELECTED Warning will occur after the VSD has
been initialized, if no "Number of Compressors
Select" jumpers are installed or if more than 1 jumper
is installed. The following warning message will be
displayed indefinitely.
UNIT WARNING:
INVALID NUMBER OF COMPRESSORS SELECTED
To clear this warning, both the control panel and VSD
control voltage must be turned OFF and the jumpers
properly installed in the VSD wiring harness.
These jumpers are factory installed in the
wire harness plug and should not require
changes.

Invalid Serial Number Warning

If the INVALID SERIAL NUMBER message appears,
immediately contact Quantech Product Technical Sup-
port. The appearance of this message may mean the
chiller has lost important factory programmed infor-
mation. The serial number can be entered using the
SERVICE key.
UNIT WARNING: INVALID SERIAL NUMBER
ENTER UNIT SERIAL NUMBER
SYS 1
SYS
SYS 1
SYS 1
MTR
1 SAT
DSCH
DSCH
CURR
DSCH
TEMP
SHEAT
FLA
TEMP
°
°
°
AMPS
F
F
F
0
83
78.6
4.4
0
83
78.6
4.4
0
83
78.6
4.4
0
83
78.6
4.4
0
83
78.6
4.4
0
83
78.6
4.4
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
SYS
SYS 1
SYS
SYS 1
1 OIL
COMP
1 FAN
ECON
TEMP
STATUS
STAGE
°
F
82
OFF
OFF
0
82
OFF
OFF
0
82
OFF
OFF
0
82
OFF
OFF
0
82
OFF
OFF
0
82
OFF
OFF
0
QUANTECH
SYS 1
MOTOR
TEMP1
°
F
107.9
107.9
107.9
107.9
107.9
107.9
