Item Quan Reference
30 1 J57
31 1 J29
32 1 J32
33 4 J43,J45,J46,J47
34 1 L1
35 3 Q1,Q5,Q9
36 3 Q2,Q6,Q10
37 6 Q3,Q4,Q7,Q8,Q11,Q12
38 2 RP5,RP1
39 1 RP2
40 1 RP3
41 1 RP4
42 37 R1,R2,R49,R54,R59,R66,R74,R80,R112,R120
,R150,R151,R152,R153,R160,R161,R163,R1
64,R184,R185,R186,R192,R193,R194,R212,
R214,R216,R222,R224,R233,R235,R242,R24
8,R249,R256,R257,R258
43 3 R6,R196,R197
44 38 R14,R17,R19,R24,R26,R28,R31,R34,R36,R4
1,R87,R88,R89,R90,R91,R92,R94,R96,R98,R
100,R102,R103,R104,R105,R106,R107,R110,
R126,R129,R130,R131,R190,R191,R198,R20
0,R239,R240,R241
45 6 R50,R55,R60,R67,R75,R81
46 3 R84,R85,R226
47 5 R86,R210,R217,R220,R229
48 5 R109,R119,R156,R169,R173
49 2 R114,R225
50 1 R117
51 1 R118
52 1 R155
53 4 R175,R187,R188,R189
54 4 R211,R221,R232,R247
55 2 R218,R228
56 1 R246
57 6 R250,R251,R252,R253,R254,R255
58 1 R259
Part Number Manufacturer
111-0104-001 JOHNSON COMPONENTS BINDING POST, GREEN
747238-4 AMP
TORX173 TOSHIBA
TOTX173 TOSHIBA
43LS475 MILLLER
MMUN2111LT1 MOTOROLA
MMUN2211LT1 MOTOROLA
2SC2878 TOSHIBA
4610X-101-103 BOURNS
4606X-101-102 BOURNS
4610X-101-102 BOURNS
4606X-101-103 BOURNS
CRCW12061002FT DALE
CRCW1206472JT DALE
CRCW1206330JT DALE
CRCW12065610FT DALE
CRCW12061001FT DALE
CRCW1206151JT DALE
CRCW1206000ZP DALE
CRCW12062R0JT DALE
CRCW12064750FT DALE
CRCW1206750JT DALE
CRCW12063320FT DALE
CRCW12061782FT DALE
CRCW12064752FT DALE
CRCW1206203JT DALE
CRCW12063302FT DALE
CRCW1206202JT DALE
CRCW1206510JT DALE
Description
CONNECTOR, D-SUB, 25-PIN, MALE, RA
OPTICAL TOSLINK RECIEVER
OPTICAL TRANSMITTER
INDUCTOR, 47UF
TRANSISTOR, PNP, SOT-23
TRANSISTOR, NPN, SOT-23
TRANSISTOR, TO-92
RES NETWORK, 10K-OHM, 10-PIN, BUSSED
RES NETWORK, 1K-OHM, 6-PIN, BUSSED
RES NETWORK, 1K-OHM, 10-PIN, BUSSED
RES NETWORK, 10K-OHM, 6-PIN, BUSSED
RES, 10K-OHM, 1206, 1%, 1/8W, METAL FILM
RES, 4.7K-OHM,1206, 5%, 1/8W, METAL FILM
RES, 33-OHM, 1206, 5%, 1/4W, METAL FILM
RES, 560-OHM, 1206, 1%, 1/4W, METAL FILM
RES, 1K-OHM, 1206, 1%, 1/8W, METAL FILM
RES, 150-OHM, 1206, 5%, 1/8W, METAL
FILM
RES, 0-OHM, 1206, 1%, 1/8W, METAL FILM
RES, 2-OHM, 1206, 5%, 1/8W, METAL FILM
RES, 470-OHM, 1206, 1%, 1/4W, METAL FILM
RES, 75-OHM, 1206, 5%, 1/4W, METAL FILM
RES, 330-OHM, 1206, 1%, 1/8W, METAL FILM
RES, 17.8K-OHM, 1206, 1%, 1/8W, METAL
FILM
RES, 47K-OHM, 1206, 1%, 1/8W, METAL FILM
RES, 20K-OHM, 1206, 5%, 1/8W, METAL FILM
RES, 33K-OHM, 1206, 1%, 1/8W, METAL FILM
RES, 2K-OHM, 1206, 5%, 1/4W, METAL FILM
RES, 51-OHM, 1206, 5%, 1/4W, METAL FILM
