Operation

5.
5.1
Make the following settings after the MICRO-EPSILON LED Check software has been installed and the color-
CONTROL MFA-5 has been connected:
5.1.1
The USB port is configured as virtual COM port and is designated as Com5, Com6 etc.
The sensor is shipped with a baud rate of 115200, see Chap.
The COM port can be between 1 and 256 from firmware version 2.0.0.1.
i
The baud rate can be set between 9600 and 115200.
Using USB mode may lead in especially noisy electromagnetic environment to functional interference in indi-
NOTICE
vidual cases. Here, a system reboot may be required.
colorCONTROL MFA-5
Operation

Commissioning

Configuration: Port (Interface)

Set the serial port to Auto and the baud rate to 115200.
The COM port must be between 1 and 8 for firmware versions older than 2.0.0.1.
A 1
