Commands

6.2.3.12 Read Distance between LED and colorCONTROL MFA-5

Command
getdistance## b
# = channel number
1 ... 5
or
# 1 ... 495,
b = board
6.2.4
6.2.4.1
Command
setcaptimexyz b
Board = colorCONTROL MFA-5
Channel = checkpoint
colorCONTROL MFA-5
getdistance## b
Description
Fetch saved distance
value in mm

Input

Set the Test Time without Test

setcaptimexyz b
Description
x = test time preselec-
tion
1 = 600 ms
2 = 200 ms
3 = 120 ms
4 = 60 ms
6 = 10 ms
7 = 2 ms
8 = can be pro-
grammed by the user
0 = off
without test - only pre-
selection
Received Example
xxx.x getdistance4
Output format
003.5
Received Example
OK setcaptime2115
or
setcatime215 3
Output format:
OK
Note
# = 1 ...5, if b =
board
# = 1 ... 495 for max.
99 boards,
b not specified.
Note
x = 2 200 ms
y = 1 Sensor High
9x9
z = 15 Sensor 5,
Board 3
z = 1 Sensor 1-5 or 1
... 495
b = board, if z = 1-5
Page 57
