Commands
6.2.2
6.2.2.1
Measures and saves the color and intensity of the LEDs.
Command
capture
This command tells the colorCONTROL MFA-5 to check and save the colors and intensity of all connected
LEDs at the same time.
The test time and the color chip sensitivity range (9x9; 3x3) can be set before the actual test using the com-
mand setcaptimexyz b, see Chap. 6.2.4.1.
colorCONTROL MFA-5

Check

General Check

capture
Description
Start color, saturation,
intensity check
Received Example
OK capture
OK
Note
Check of all color-
CONTROL MFA-5
and their check-
points with current
settings.
Page 46
