Commands
6.2.2.3
Measures and saves the color and intensity of pulsed (PWM) LEDs.
Command
capturepwm
PWM LED = Pulse Width Modulated LED
This command tells the colorCONTROL MFA-5 to check and save the colors and intensity of all connected
LEDs.
Thereby, a default setting is used which is sufficient for most LEDs.
However, it is recommended to set the preselection manually to achieve better results for different LEDs, see
Chap. 6.2.2.4.
colorCONTROL MFA-5

General Check of Pulsed LEDs

capturepwm
Description
Start PWM color, intensity
check
Received Example
OK capturepwm
OK
Note
Check of all color-
CONTROL MFA-5
and sensors with
current settings.
Page 49
