Adash 4500 – VA5Pro
Enter Speed
This function is available by pushing the bottom left button. This button can have various names depending of
mode (Analyzer, Route) and displayed screen (Project, Machine, Set, Point, Meas).
The manual entered speed value will be saved to all next readings. It is saved to the same position in the head
of data as the speed measured by tacho. If the speed is manually entered and also measured by tacho, then the
tacho has priority and it is saved.
The manually entered speed is displayed on the right side at the top of the screen with the word "Speed:"
You should notice, that the speed value is saved to the head of data. That is why you have to use the Tacho
factor ( Machine or Point Properties) in DDS for recalculation of speed to other ratios.
The Gear Ratio (in Properties) is used with Default Speed value not with the speed value in data head. The
Default speed is defined by user in Properties. It is used with machines, which have constant speed (always the
same value).
Cancel Speed
It cancels (removes) manually entered speed value.
The Cancel speed function is also available in Route.
Notes
You can attach the short text notes to tree item in the route. There are three ways how to handle with notes.
1. Enter the note manually.
2. Select predefined note from Factory notes set.
3. Select predefined note from User notes. This set is created and edited by user.
Press the button on the left bottom (it can have more names as Route, Machine or Point). Select Notes item.
The list of existed notes for selected item appears. It is empty when no note was created yet.
90
