ADASH


Selection of machine image, different images are available for single and dual plane balancing
Look
left, right view direction (only for single plane balancing)
Rotation
CW, CCW
clockwise or counterclockwise
Inputs
single, dual one or two AC inputs (sensors) can be used (only for dual planes balancing)
Channel
The number of AC input, which will be used for sensor mounted on the bearing, for single plane balancing
Channel A, Channel B
Numbers of AC inputs, which will be used for sensors mounted on the bearings, for dual planes balancing
Note: The bearing marking A and B has only the symbolic sense. It has no relation to the balancing planes 1,2
and to the balancing computational procedure. You can mark any bearing as A and the second as B.
Balancing Masses
add (mount) / remove (drill)
Blades
the number of blades ( for rotors with blades). This parameter is used in job figuring to split the mass to blades.
Meas Mode
single, online meter
when you push the Start button, then only one measurement value can be taken (single) or the continual
measurement values displayed (online meter). In online meter mode you can look at more values and to
evaluate the changing of them in time. You need to STOP the measurement, when is displayed the value, which
you want to use.
Avg
The averaging of more then one measured values is available
Resolution
Read the explanation in the Edit Measurement caption for the Analyzer module.
