ADASH
Sleep Mode
Use the POWER button (described in the "Switch on" chapter) to switch the instrument into a sleep mode. The
screen is off and power consumption is lower in the sleep mode. Use the same POWER button to wake up
again.
Note! You can use any button to wake the instrument up. However notice the button press isn't ignored by the
system even in the sleep mode and the press can cause some unexpected event in the application. The
reaction to the button press is same like not being in the sleep mode.
Auto Switch off
If no button is pushed in 5 minutes from switching on, the instrument will be switched off.
Emergency Switch off
This is not correct method to switch off the instrument. Using it can cause data corruption. Use this method only
in case of emergency (eg. when the system freezes).
Push and hold the POWER button for about 10 seconds. Instrument will switch off.
Capacity Warning
If this warning message appears, you need to get free disc space by removing the measurements, routes or
records, which are not needed.
Connection to the computer
VA5_DISC
All data like projects, measurements, readings, setups and so on are stored to a high capacity hard disk which
is intended for internal purposes only. Furthermore the instrument contains the VA5_DISC, it is flash memory,
which is accessible from external computer. The VA5_DISC is an interface for data. For example, you save a
route from DDS to the VA5_DISC, the instrument copies it automatically to hard disk. Then you measure the
route and then you export the route back to the VA5_DISC. Here you can read it from computer. You don't need
to export all data from internal hard disk. Export only the data which you want to read from computer. A detailed
description how to export will be stated later in chapters about project's control for each module.
Connection
To make a connection between computer and instrument (more precisely VA5_DISC) use the USB cable which
is the standard accessory of VA5 set.
The connection to PC is indicated by icon located on the bottom right corner next to battery icon. For data
download you must be in the main screen.
For further technical and contact information visit
16
www.adash.com
or email: info@adash.com
Adash 4500 – VA5Pro
