Parts Needed; Sim Card - OVMS User Manual

OVMS: Renault Twizy User Guide

Parts needed

You can buy all parts at the OVMS hardware partner Fasttech:
http://www.fasttech.com/link/ovms
Note: Fasttech is shipping from China, import customs and tax will apply for EU.
For each Twizy you'll need:
Universal GPS Antenna (SMA Connector)
•
GPS Antenna: SMA: $4.89
OpenVehicles OVMS GSM Antenna
•
GSM Antenna: $2.50
ODB-II to DB9 Data Cable for OVMS
•
ODB-II OVMS Cable: $9.50
OVMS Car Module v2
•
OVMS Module: $99.00
If you want to avoid having two antennas: There are combi antennas integrating GSM & GPS
available (e.g. "shark fin antenna"). If you test one of these, please report your results :-). Both
antenna connectors are SMA, an active GPS antenna needs to run on 3 V.
To update the OVMS firmware, you'll also need one of these:
PICKIT 2 Compatible Programmer/Debugger
•
PICKIT 2 Compatible Programmer: $16.99
PICKIT 3 Compatible Programmer/Debugger
•
PICKIT 3 Compatible Programmer: $26.28
If you want to do OVMS development and/or debugging, a serial interface or serial to USB adapter
will be needed.

SIM card

You'll need a standard size SIM card with a data plan. The Twizy module will normally need about
1-10 MB of data per month, depending on your driving and GPS logging. Data though will be sent
in small and infrequent packets, so be aware of providers rounding up prepaid data transfers (like
Congstar.de) or book some minimal flat rate. Also, mobile GPRS coverage and stability depends
on the network; for Germany, D1 (T-Mobile) offers best coverage and stability, followed by D2
(Vodafone). E-Plus is usable in urban areas, O2 is not recommended.
Some pointers for Germany (conditions may have changed!):
T-Mobile "Xtra Call" + "Xtra Flat Daten": D1, best coverage, flat rate required, limit 50 MB
•
(should be sufficient in most cases)
(left)
