OVMS: Renault Twizy User Guide
All values mentioned above refer to the Twizy 80. The Twizy 45 limits are lower, see spreadsheet
"Twizy-Limits" and "Twizy-SDO-List" for details. In short:
– maximum battery discharge power is 10.5 kW (T80: 18 kW)
– maximum configurable speed is 78 kph
– maximum torque will be at 111% = 36 Nm (default: 32.5 Nm)
– power levels of 130% can be configured, but watch temperatures! Default max power is
~7650 W = ~191% of continuous specs. 130% will raise this to ~9950 W = ~249% – the
battery limit will probably cut this down.
– default recuperation levels are 21% (instead of 18%, maybe due to the lower torque)
– default ramps are 3% for start and 21% for acceleration (T80: 4% & 25%)
– TSMAP points are at the same speeds (except drive map, which may be a config error)
Note: the "Twizy-Powermap-Calculator" also contains a Twizy 45 sheet.
