7. Check Mode

Check 1: Sensor condition of the air conditioner is monitored and indicated.
Check 2: Sensor data of the air conditioner prior to alarm occurrence is indicated.
(1) Press and hold " ", " " for "Temp" and "Fan"
simultaneously for at least 3 seconds during the normal
mode.
(2) Select the "Check" mode by pressing " " or " " for "Temp"
and press "Fan".
(3) Select the indoor unit by pressing " " or " " for "Temp"
and press "Fan".
(4) Press " " or " " for "Temp" and select the item.
(5) Press " " or " " for "Temp" simultaneously to return to
the normal mode.
NOTE:
The "check" items are different for each indoor unit type. Check the service manual for the indoor unit to be used
for the detailed information.

8. Reset of Controller

Reset the EEPROM inside the controller.
(1) Press " " and " " for "Temp" and "Fan" simultaneously
during the normal mode (when unit is not operated).
(2) Press " " and " " for "Temp" and "Fan" simultaneously
again when the screen is switched as shown on the right.
(3) Reset EEPROM.
When the fi gure on the right is displayed, press " " for
"Temp" or leave it for 15 seconds, then EEPROM data
will be deleted.
(4) After a few seconds, the controller will restart automatically.
After resetting, shut off the indoor unit power supply.
After indication on the remote controller turns OFF, turn the power ON for indoor unit again.
16
01: Check 1
02: Check 2
