Johnson Controls CIS01 Installation & Maintenance Manual page 17

Table B Input and Output Number Display and Connectors
Input Number Display
Input/Output Indication
Input 1
Input 2
Output 1
Output 2
Output 3
Table C Input and Output Settings and Display Codes
Indication
00 Not set
01 Room Thermostat (for Cooling)
02 Room Thermostat (for Heating)
03 Remote ON/OFF 1 (Level)
04 Remote ON/OFF 2 (Operation)
05 Remote ON/OFF 2 (Stoppage)
06 Forbidding Remote Control after Manual Stoppage
07 Remote Cooling / Heating Change
09 Setback Operation
NOTE:
* Power on, wait 3 minutes and then change the optional setting.
* Do not set the elevating grille for the total heat exchanger.
* Record the setting conditions for each input and output in the "Setting" column of the table.
P5415520
Port
CN3 1-2 Remote ON/OFF 1 (Level)
CN3 2-3 Prohibiting Remote Control after Manual Stoppage
CN7 1-2 Operation
CN7 1-3 Alarm
CN8 1-2 Thermo-ON for Heating
Input
Factory Setting
Setting Item
Not set
Operation
Alarm
Cooling
Thermo-ON for Cooling
Heating
Thermo-ON for Heating
Not set
Setting
Indication
03
06
01
02
06
Output
15
