PolarFire FPGA 1G Ethernet Loopback Using IOD CDR
Table 1 •
Requirement
Libero SoC Design Suite
2.2

Prerequisites

Before you start:
1. Download the reference design files from:
http://soc.microsemi.com/download/rsc/?f=mpf_dg0799_eval_liberosocv12p1_df
2. Download and install Libero SoC v12.1 on the host PC from
https://www.microsemi.com/product-directory/design-resources/1750-libero-soc#downloads
3. The latest versions of ModelSim and Synplify Pro are included in the Libero SoC PolarFire
installation package. Make sure you have a Libero Gold license for design evaluation on MPF300
device. A one year Gold software License is included with the Evaluation kit.
4. If you already purchased a Gold license and received a Software ID from Microsemi, generate your
Gold License using the following link:
https://soc.microsemi.com/portal/default.aspx?r=1
5. Download Cat Karat and Wireshark.
2.3

Demo Design

The following is the data flow for the 1G Ethernet loopback demo design:
1. PF_CCC_0 provides the clock to the Mi-V processor and other APB peripherals.
2. PF_IOD_CDR_CCC_C0 generates:
• The fabric transmit clock ((TX_CLK_G)) for the CoreTSE block.
• The high-speed bank clocks, and drives the high-speed clocks (HS_IO_CLKs) of the
PF_IOD_CDR_C0 block for clock recovery.
3. PF_IOD_CDR_CCC_C0 also generates Delay codes for the PVT compensation.
4. Mi-V performs the following functions:
• Executes the application from LSRAM (PF_SRAM IP).
• Configures the ZL30364 clock generation hardware through the CoreSPI IP to generate
reference clocks for the VSC PHY and the IOD CDR fabric module.
• Configures the Management registers of CoreTSE and VSC PHY.
• Sends a request to the CoreTSE IP to negotiate with the on-board VSC8575 PHY.
5. CoreTSE IP implements 1G Ethernet MAC and is configured in ten bit interface mode (TBI) to
interface with the PF_IOD_CDR_C0. The CoreTSE IP has an inbuilt MDIO interface to exchange
control and status information with the VSC PHY.
6. PF_IOD_CDR IP does the following:
• Interfaces with the on-board VSC8575 PHY and forms the SGMII link.
• Recovers the data and clock from the incoming RX_P and RX_N ports.
• Sends the recovered clock (RX_CLK_R) to the CoreTSE block.
• Deserializes the recovered data and sends 10-bit parallel data to CoreTSE.
• Receives Ethernet data via the RX_P and RX_N input pads, gears down the receive data rate,
and deserializes the data.
• The deserialized data is sent from PF_IOD_CDR_C0:RX_DATA[9:0] to CoreTSE IP: RCG[9:0].
• The received data is looped back at the CoreTSE IP, and CoreTSE IP:TCG[9:0] is sent to
PF_IOD_CDR_C0:TX_DATA[9:0].
• PF_IOD_CDR_C0 serializes the data, gears up the transmit data rate, and transmits the data to
the on-board VSC PHY via the TX_P and TX_N output pads.
Figure 1, page 4 shows the hardware implementation of the demo design.
